Kia Soul II (2013-2016) leak current autocut device switch Wiring diagram
This page shows the only wiring diagram for the component.leak current autocut device switch, which is found in the car Kia Soul II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram leak current autocut device switch (1 of 1)
1 2 3 4 5 6 MEMORY PWR ON/START I/P C-CAN LOW C-CAN HIGH
4.2 INCH
BLK WIRE
BLU WIRE
BRN WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
GROUND
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES E/R FUSE, RELAY BOX B+ 3 (LEFT FUSE SIDE OF ENGINE COMPT)
HOT IN ON OR START
I/P-D
I/P-F
INSTRUMENT CLUSTER
IOD 4 MODULE FUSE FUSE
LEAK CURRENT AUTOCUT DEVICE
LEAK CURRENT AUTOCUT DEVICE RELAY
LEAK CURRENT AUTOCUT DEVICE RLY CTRL IPS CONTROL MODULE
LEAK CURRENT AUTOCUT DEVICE SWITCH
LEFT FRONT TIRE PRESSURE SENSOR
LEFT REAR TIRE PRESSURE SENSOR
MICOM
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED/ORG WIRE
RIGHT FRONT TIRE PRESSURE SENSOR
RIGHT REAR TIRE PRESSURE SENSOR
SMART JUNCTION BOX (LEFT END OF DASH)
TFT
TFT LCD
TIRE PRESSURE MONITORING MODULE (RIGHT SIDE OF DASH)
TRANSCEIVER C-CAN
WHT WIRE
Go to component -> Tire pressure monitoring circuit -> LEAK CURRENT AUTOCUT DEVICE SWITCH
