Kia Soul II (2013-2016) driver front height adjuster up switch Wiring diagram
This page shows the only wiring diagram for the component.driver front height adjuster up switch, which is found in the car Kia Soul II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver front height adjuster up switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BWD
BWD FWD
DRIVER FRONT HEIGHT ADJUSTER MOTOR
DRIVER FRONT HEIGHT ADJUSTER UP SWITCH
DRIVER LUMBAR
DRIVER LUMBAR SUPPORT SWITCH FWD
DRIVER REAR HEIGHT ADJUSTER MOTOR
DRIVER REAR HEIGHT ADJUSTER SWITCH
DRIVER RECLINING
DRIVER RECLINING LIMIT SWITCH
DRIVER RECLINING SWITCH FWD
DRIVER SEAT MANUAL SWITCH
DRIVER SLIDE MOTOR
DRIVER SLIDE SWITCH
FWD (ON DRIVER'S LEFT SEAT BACK HINGE ASSEMBLY)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
I/P-C
J/C
MOTOR
NCA WIRE
P/SEAT (DRV) FUSE
PNK WIRE
RED WIRE
SEAT)
SMART JUNCTION BOX
SUPPORT MOTOR
WHT WIRE
YEL WIRE
Go to component -> Power seat circuit -> DRIVER FRONT HEIGHT ADJUSTER UP SWITCH
