Kia Soul II (2013-2016) c-can lo c-can hi Wiring diagrams

This page contains all the electrical diagrams for the component. c-can lo c-can hi, in which he is found in the car Kia Soul II (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram c-can lo c-can hi (1 of 4)

Wiring diagram c-can lo c-can hi for Kia Soul II (2013-2016) (1 of 4)

Get access

2.0L A/T M/T ACC RELAY B-CAN HI B-CAN LO ACC/ON INPUT ON INPUT BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/ORG WIRE BUTTON C-CAN LO C-CAN HI COMPUTER DATA LINES SYSTEM E/R FUSE, RELAY BOX (LEFT SIDE OF E/R JUNCTION BOX E/R-B E/R-C E/R-D ELECTRONIC STEERING COLUMN LOCK COM EMS COM ELECTRONIC STEERING COLUMN LOCK GND GND GND ENGINE RPM SIG FUSE FUSE ENGINE COMPT) GND PWR GRN WIRE GRN/ORG WIRE GRY WIRE HOT AT ALL TIMES I/P-F I/P-G MODULE 5 FUSE FUSE ON/START INPUT ORG/ WIRE ORG/BLK WIRE PASS TOGGLE BUTTON DRIV TOGGLE BUTTON PDM 1 FUSE PDM 2 FUSE ECU FUSE PNK WIRE PNK/BLK WIRE RED WIRE RELAY SMART JUNCTION BOX (LEFT END OF DASH) SMART KEY ANTENNA 1 (UNDER FLOOR CONSOLE) SMART KEY ANTENNA 2 (UNDER CENTER OF REAR SEAT) SMART KEY BUMPER ANTENNA (BEHIND CENTER OF REAR BUMPER) SMART KEY CONTROL MODULE (LEFT END OF DASH) STARTING/CHARGING SYSTEM WHEEL SPEED "P" POSITION SW IGN LK SW WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE

Go to component -> Immobilizer circuit, with smart key system (1 of 3) -> C-CAN LO C-CAN HI

Wiring diagram c-can lo c-can hi (2 of 4)

Wiring diagram c-can lo c-can hi for Kia Soul II (2013-2016) (2 of 4)

Get access

ANTENNA BLK WIRE BLU WIRE BLU/BLK WIRE BPF LNA LNA BRN WIRE C-CAN LO C-CAN HI COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM GPS GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON SMART JUNCTION BOX (LEFT END OF DASH) FUSE HOT IN ON OR START I/P-F IOD 2 FUSE LEAK CURRENT AUTOCUT DEVICE M-CAN LO M-CAN HI MATCHING CIRCUIT MEM POWER ON/STRT I/P ACC/ON I/P CRASH SIG MODULE 3 FUSE MTS MODULE (LEFT SIDE OF DASH) NCA WIRE ORG/ WIRE RED WIRE RFC SPEED SIG SUPPLEMENTAL RESTRAINTS SYSTEM WHT WIRE YEL WIRE

Go to component -> Mobile telematic system circuit -> C-CAN LO C-CAN HI

Wiring diagram c-can lo c-can hi (3 of 4)

Wiring diagram c-can lo c-can hi for Kia Soul II (2013-2016) (3 of 4)

Get access

10 9 8 7 6 5 4 3 2 PNK ON/START INPUT WIRE 8 7 6 5 4 3 2 MOTOR POWER W MOTOR POWER V MOTOR POWER U BLK WIRE BLK/ORG WIRE BRN WIRE C-CAN LO C-CAN HI COMPUTER DATA LINES SYSTEM E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT) HALL SNSR POWER HALL SNSR GND HOT AT ALL TIMES HOT IN ON OR START I/P-E INVERTER FUSE MULTI FUSE OIL PUMP (LOWER LEFT REAR OF ENGINE) OIL PUMP INVERTER (UPPER LEFT FOOTWELL) PNK WIRE RED WIRE SMART JUNCTION BOX (LEFT END OF DASH) TCU FUSE WHT WIRE YEL WIRE

Go to component -> Wiring diagram engine performance 1.6l, electric oil pump circuit -> C-CAN LO C-CAN HI
