Kia Soul II (2013-2016) c-can high cmps 1 intake gnd cmps 1 intake sig Wiring diagram
This page shows the only wiring diagram for the component.c-can high cmps 1 intake gnd cmps 1 intake sig, which is found in the car Kia Soul II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram c-can high cmps 1 intake gnd cmps 1 intake sig (1 of 1)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN HIGH CMPS 1 INTAKE GND CMPS 1 INTAKE SIG
C-CAN LOW CMPS 2 EXHAUST GND CMPS 2 EXHAUST SIG
CKPS GND
CKPS SIG
COMPUTER DATA LINES SYSTEM
CRANKSHAFT POSITION SENSOR (LEFT REAR OF ENGINE)
E/R JUNCTION BOX
E/R-A
E/R-B
E/R-C
ECM (ENGINE CONTROL MODULE) (LEFT REAR OF ENGINE COMPT)
ECU 2 FUSE
ECU 3 FUSE
ENGINE CONTROL RELAY
ENGINE CTRL RLY CTRL START RLY CTRL
F/PUMP FUSE
F/PUMP RELAY
F/PUMP RLY CTRL CCV CTRL
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
IGN ECU 1 COIL FUSE FUSE
IMMO COMMUNICATION LINE
INTAKE OIL CONTROL VALVE 1 (LEFT FRONT OF ENGINE)
NCA WIRE
ORG/ WIRE
OXYGEN SENSOR (UP) (EXHAUST MANIFOLD)
PCSV CTRL
PNK OXYN SNSR UP VIRTUAL GND OXYN SNSR UP PMPNG CURNT WIRE
PNK WIRE
RED WIRE
RPS SIG
SENSOR 1 FUSE
START SW I/P LIN COMMUNICATION
STARTING/ CHARGING SYSTEM
W/ IMMO, SMART KEY W/O IMMO, SMART KEY
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l, mfi control circuit, m/t (1 of 6) -> C-CAN HIGH CMPS 1 INTAKE GND CMPS 1 INTAKE SIG
