Kia Soul II (2013-2016) blk Wiring diagrams

This page contains all the electrical diagrams for the component. blk, in which he is found in the car Kia Soul II (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

blk wiring diagram (111 of 118)

4 3 B-CAN LOW B-CAN HIGH 8 9 C-CAN LOW C-CAN HIGH AJAR BCM (CENTER OF DASH) BLK WIRE BLK/ORG WIRE BOX (LEFT END OF DASH) BRN WIRE BRN/ORG WIRE BUZZER C-CAN TRANSCEIVER CLUSTER FUSE COMPUTER DATA LINES SYSTEM DOOR OPEN IND DRIVER DOOR LOCK ACTUATOR DRIVER SEAT BELT BUCKLE SWITCH DRIVER SEAT BELT BUCKLE SWITCH (IN DRIVER SEAT BELT BUCKLE ASSEMBLY) GND PWR GRN WIRE GROUND DISTRIBUTION SYSTEM HOT IN ON OR START HOT W/ LEAK CURRENT AUTOCUT DEVICE RELAY ENERGIZED I/P-B I/P-F I/P-G IGNITION KEY ILLUMINATION, DOOR WARNING SWITCH ILL INSTRUMENT CLUSTER IOD 1 FUSE IPS CONTROL MODULE KEY ILL CTRL KEY-IN SWITCH LEAK CURRENT AUTOCUT DEVICE LEFT REAR DOOR LOCK ACTUATOR LEFT REAR DRIV DOOR DOOR AJAR AJAR B-CAN SIG HIGH SIG MICOM MULTI-FUNCTION SWITCH LIGHT SWITCH HEAD TAIL AUTO OFF NAVIGATION SYSTEM COMPUTER DATA LINES SYSTEM NCA WIRE ORG/ WIRE PASS DOOR B-CAN AJAR LOW SIG PASSENGER DOOR LOCK ACTUATOR PNK TAIL LAMP SW WIRE PNK WIRE RED WIRE RIGHT REAR DOOR AJAR SIG RIGHT REAR DOOR LOCK ACTUATOR SEAT BELT IND SMART JUNCTION W/O SMART KEY WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL/ORG WIRE

Go to component -> Chime circuit -> BLK WIRE

blk wiring diagram (112 of 118)

1.6L 2 15 1 12 21 FRONT WASHER REAR WASHER ON INPUT WIPER RLY CTRL WIPER RLY CTRL 2.0L 22 14 10 11 5 9 INT TIME HI INT LO MIST WASHER SIG 32 33 COMPUTER DATA LINES SYSTEM SIG 1 GND A/T BCM (CENTER OF DASH) BLK WIRE BLU WIRE BRN WIRE C-CAN DELAY CONTROL E/R JUNCTION BOX E/R-A E/R-B ECM (M/T) PCM (A/T) (LEFT REAR OF ENGINE COMPT) FRONT WIPER (LOW) RELAY FRONT WIPER HIGH RELAY FRONT WIPER MOTOR (LEFT REAR ENGINE COMPT) FRONT WIPER SWITCH GRN WIRE GRN/ORG WIRE GRY WIRE HOT IN ON HOT IN ON OR START SMART JUNCTION BOX CLUSTER (LEFT END FUSE OF DASH) I/P-C I/P-F INSTRUMENT CLUSTER J/C JOINT CONNECTOR LO INT OFF HI M/T MICOM MIST SWITCH MULTI- FUNCTION SWITCH OFF ORG/ WIRE PARKING SWITCH PCM (LEFT REAR OF ENGINE COMPT) PNK WIRE TRANSCEIVER/ WASHER LEVEL SENSOR (IN WASHER FLUID RESERVOIR) WASHER SWITCH WHT WIRE WIPER FRT 1 FUSE WIPER FRT 2 FUSE WIPER FUSE WIPER SWITCH INPUT WIPER WASHER MOTOR (ON WASHER FLUID RESERVOIR) YEL WIRE YEL/BLK WIRE

Go to component -> Front wiper/washer circuit -> BLK WIRE

blk wiring diagram (113 of 118)

B-CAN B-CAN HIGH LOW B-CAN HIGH B-CAN LOW BCM (CENTER OF DASH) BLK WIRE BLU WIRE BLU/BLK WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE HOT IN ON I/P-C I/P-G IPS CONTROL MODULE MULTI- FUNCTION SWITCH ORG/ WIRE PARKING SWITCH PNK/BLK WIRE REAR INT WIPER SWITCH ON OFF REAR OFF WASHER ON SWITCH REAR WIPER MOTOR (CENTER OF TAILGATE DOOR) REAR WIPER RELAY REAR WIPER RLY REAR WIPER SWITCH INT REAR WIPER SWITCH ON REAR WASHER SW SMART JUNCTION BOX (LEFT END OF DASH) WHT WIRE WIPER RR FUSE YEL/BLK WIRE

Go to component -> Rear wiper/washer circuit -> BLK WIRE

blk wiring diagram (114 of 118)

12 13 HIGH LOW LOW HIGH BLK WIRE BLU WIRE BRN WIRE DRIVER ANCHOR PRETENSIONER (BASE OF LEFT "B" PILLAR) DRIVER PRESSURE SIDE IMPACT SENSOR (IN DRIVER DOOR) DRIVER SEAT BELT PRETENSIONER (BASE OF LEFT "B" PILLAR) GRN WIRE HIGH LOW LOW HIGH LOW HIGH HIGH LOW LOW HIGH 22 23 ORG/ WIRE ORG/BLK WIRE PASSENGER ANCHOR PRETENSIONER (BASE OF RIGHT "B" PILLAR) PASSENGER SEAT BELT BUCKLE SWITCH (IN PASSENGER SEAT BELT BUCKLE ASSEMBLY) PASSENGER SEAT BELT PRETENSIONER (BASE OF RIGHT "B" PILLAR) RED WIRE SRS CONTROL MODULE (UNDER FRONT OF FLOOR CONSOLE) WHT WIRE YEL WIRE

Go to component -> Supplemental restraints circuit (3 of 3) -> BLK WIRE

blk wiring diagram (115 of 118)

B-CAN B-CAN HIGH LOW BLK WIRE BRN WIRE C-CAN TRANSCEIVER CLUSTER FUSE COMPUTER DATA LINES SYSTEM FUEL CAP OPEN IND (W/ DOT LCD) GRN WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT IN ON OR START I/P-A I/P-B I/P-F I/P-G INSTRUMENT CLUSTER IPS CONTROL MODULE MICOM NCA WIRE ORG/ WIRE PNK WIRE PTC TAIL GATE OPEN MOTOR SWITCH SIG 1 GND SMART JUNCTION BOX (LEFT END OF DASH) T/GATE OPEN FUSE T/GATE OPEN RELAY TAIL GATE HANDLE SW TAIL GATE OPEN SW TAIL GATE RLY CTRL TAIL- GATE HANDLE SWITCH TAILGATE LATCH (BOTTOM CENTER OF TAILGATE) TRUNK OPEN IND WHT WIRE

Go to component -> Tailgate release circuit -> BLK WIRE

blk wiring diagram (116 of 118)

1 2 3 4 5 6 MEMORY PWR ON/START I/P C-CAN LOW C-CAN HIGH 4.2 INCH BLK WIRE BLU WIRE BRN WIRE CLUSTER FUSE COMPUTER DATA LINES SYSTEM GROUND GROUND DISTRIBUTION SYSTEM HOT AT ALL TIMES E/R FUSE, RELAY BOX B+ 3 (LEFT FUSE SIDE OF ENGINE COMPT) HOT IN ON OR START I/P-D I/P-F INSTRUMENT CLUSTER IOD 4 MODULE FUSE FUSE LEAK CURRENT AUTOCUT DEVICE LEAK CURRENT AUTOCUT DEVICE RELAY LEAK CURRENT AUTOCUT DEVICE RLY CTRL IPS CONTROL MODULE LEAK CURRENT AUTOCUT DEVICE SWITCH LEFT FRONT TIRE PRESSURE SENSOR LEFT REAR TIRE PRESSURE SENSOR MICOM PNK WIRE POWER DISTRIBUTION SYSTEM RED/ORG WIRE RIGHT FRONT TIRE PRESSURE SENSOR RIGHT REAR TIRE PRESSURE SENSOR SMART JUNCTION BOX (LEFT END OF DASH) TFT TFT LCD TIRE PRESSURE MONITORING MODULE (RIGHT SIDE OF DASH) TRANSCEIVER C-CAN WHT WIRE

Go to component -> Tire pressure monitoring circuit -> BLK WIRE

blk wiring diagram (117 of 118)

1 5 60 77 GROUND MEMORY PWR C-CAN HIGH C-CAN LOW 1.6L 1.6L, 2.0L ATM SOLENOID (TOP OF TRANSAXLE) BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE CLUSTER FUSE E/R FUSE, RELAY ECU 5 FUSE BOX (LEFT SIDE OF ENGINE COMPT) EXTERIOR LIGHTS SYSTEM COMPUTER DATA LINES SYSTEM GRN WIRE GRN/ORG WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN ON OR START I/P-E I/P-F INPUT SPEED SENSOR MODULE 3 FUSE ON/START IN ORG/ WIRE ORG/BLK WIRE OUT SPD SIG OUT SPD PWR IN SPD SIG IN SPD PWR SOL PWR 1 SOL PWR 2 SS A OUTPUT SPEED SENSOR P/N SW PCM (LEFT REAR ENGINE COMPT) PNK 2 3 4 5 WIRE PNK WIRE RED WIRE RED/BLK WIRE SELECT SW UP SHIFT DOWN SHIFT SENSOR TEMPERATURE OIL SIG (1) SIG (2) SIG 3 SIG 4 SMART JUNCTION BOX SS A SS B STARTING/ CHARGING SYSTEM TCU FUSE VFS LINE VFS OD VFS OD VFS T/CON SS B VFS T/CON VFS UD VFS UD VFS LINE OIL TEMP SNSR + OIL TEMP SNSR - WHT WIRE YEL WIRE

Go to component -> Transmission circuit (1 of 2) -> BLK WIRE

blk wiring diagram (118 of 118)

A/V, NAVIGATION HEAD UNIT ATM LEVER INDICATOR BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/ORG WIRE C-CAN TRANSCEIVER COMPUTER DATA LINES SYSTEM D IND DOWN SHIFT GRN WIRE GRN/ORG WIRE GROUND DISTRIBUTION SYSTEM GROUND DISTRIBUTION SYSTEM JOINT CONNECTOR GRY WIRE GRY/ORG WIRE ILL INSTRUMENT CLUSTER JOINT CONNECTOR MICOM N IND ORG/ WIRE P IND P POSITION PNK 2 3 4 5 WIRE PNK WIRE R IND RED WIRE S OUT D OUT N OUT R OUT P OUT 10 9 8 7 6 39 S(-) IND SELECT SPORT MODE SWITCH SWITCH UP SHIFT WHT WIRE YEL WIRE

Go to component -> Transmission circuit (2 of 2) -> BLK WIRE
