Kia Soul II (2013-2016) a/con comp rly ctrl Wiring diagrams
This page contains all the electrical diagrams for the component. a/con comp rly ctrl, in which he is found in the car Kia Soul II (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/con comp rly ctrl (1 of 2)
47 48 49 50 CMPS 2 (EXHAUST) SIG
A/CON COMP RLY CTRL
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/ GRY WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN LOW CKPS GND CKPS SIG CMPS 1 (INTAKE) GND
CMPS 1 (INTAKE) SIG START SW I/P ON/START I/P
COMPUTER DATA LINES SYSTEM
CRANKSHAFT POSITION SENSOR (LEFT REAR OF ENGINE)
CVVT 1 CTRL (INTAKE) IGNITION COIL CTRL 1
E/R JUNCTION BOX
E/R-A
E/R-B
E/R-C
ECU 2 FUSE
ECU 3 FUSE
ENGINE CONTROL RELAY
F/PUMP FUSE
F/PUMP RELAY
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
IGN ECU 1 COIL FUSE FUSE
IGNITION COIL CTRL 3
IGNITION COIL CTRL 4 ENGINE CTRL RLY ON I/P
INTAKE OIL CONTROL VALVE 1 (LEFT FRONT OF ENGINE)
PCM (LEFT REAR ENGINE COMPT)
PNK WIPER OPERATION I/P ENGINE CTRL RLY CTRL WIRE
RED WIRE
SENSOR 1 FUSE
START RLY CTRL
STARTING/CHARGING SYSTEM
VISV CTRL
W/ SMART KEY/IMMO W/O SMART KEY/IMMO
WHT WIRE
WHT/BLK WIRE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l, mfi control circuit, a/t (1 of 7) -> A/CON COMP RLY CTRL
Wiring diagram a/con comp rly ctrl (2 of 2)
3 4 PNK WIRE
A/CON COMP RLY CTRL
AIR CONDITIONING SYSTEM
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRAKE LIGHT SW
BRAKE TEST SW
BRN WIRE
C/FAN RLY CTRL HIGH
CANISTER CLOSE VALVE (LEFT REAR OF FUEL TANK)
CCV CTRL
CLUTCH SW
COOLING FANS SYSTEM
CVVT 1 CTRL (INTAKE)
CVVT 2 CTRL EXHAUST
ECM (ENGINE CONTROL MODULE)
ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE)
ETC MOTOR, +/-
ETCS GND
ETCS SIG
EXHAUST OIL CONTROL VALVE 2 (RIGHT FRONT OF ENGINE)
F/PUMP RLY CTRL
FPCV (-)
FTPS SIG
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
IGNITION COIL CTRL 1
IGNITION COIL CTRL 2
IGNITION COIL CTRL 3
IGNITION COIL CTRL 4
INJECTOR 1 CTRL
INJECTOR 2 CTRL
INJECTOR 3 CTRL
INJECTOR 4 CTRL
KNOCK SENSOR GND
KNOCK SENSOR SIG
NCA WIRE
ORG/ WIRE
OXY SNSR (UP) HEATER
OXY SNSR DWN HEATER
OXYGEN SENSOR (DOWN) (IN EXHAUST, DOWNSTREAM OF CATALYTIC CONVERTER)
PNK 10 11 12 13 14 15 16 17 WIRE
PNK 13 14 15 WIRE
PNK 24 25 26 WIRE
PNK WIRE
RED WIRE
W/ IMMO, SMART KEY W/O IMMO, SMART KEY
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l, mfi control circuit, m/t (4 of 6) -> A/CON COMP RLY CTRL
