Kia Soul II (2013-2016) acc/on i/p m-can low m-can high Wiring diagram
This page shows the only wiring diagram for the component.acc/on i/p m-can low m-can high, which is found in the car Kia Soul II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram acc/on i/p m-can low m-can high (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 CENTER (+)
ACC/ON I/P M-CAN LOW M-CAN HIGH
AMP (UNDER PASSENGER'S SEAT)
AMP FUSE
ANTENNA
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BPF LNA LNA
BRN WIRE
CENTER SPEAKER
COMPUTER DATA LINES SYSTEM
DRIVER DOOR SPEAKER
FL (-)
FR (-)
GND GND
GPS
GRN WIRE
HOT AT ALL TIMES
I/P-A
JOINT CONNECTOR
LEFT REAR RIGHT REAR DOOR SPEAKER DOOR SPEAKER
MATCHING CIRCUIT
MATCHING MATCHING CIRCUIT CIRCUIT
MEMORY PWR MEMORY PWR CENTER (-)
MOOD LAMP MODULE
NCA WIRE
ORG/ WIRE
PASSENGER DOOR SPEAKER
RADIO
RED WIRE
RED/ORG WIRE
RFC
RFC B+
SIRIUS
SMART JUNCTION BOX (LEFT END OF DASH)
SPDIF GND SPDIF OUT(-) SPDIF OUT(+)
SUB WOOFER SPEAKER
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit, without navigation with uvo & amplifier (3 of 3) -> ACC/ON I/P M-CAN LOW M-CAN HIGH
