Kia Soul II (2013-2016) 32 33 computer data lines system sig 1 gnd Wiring diagram
This page shows the only wiring diagram for the component.32 33 computer data lines system sig 1 gnd, which is found in the car Kia Soul II (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 32 33 computer data lines system sig 1 gnd (1 of 1)
1.6L
2 15 1 12 21 FRONT WASHER REAR WASHER ON INPUT WIPER RLY CTRL WIPER RLY CTRL
2.0L
22 14 10 11 5 9 INT TIME HI INT LO MIST WASHER SIG
32 33 COMPUTER DATA LINES SYSTEM SIG 1 GND
A/T
BCM (CENTER OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
C-CAN
DELAY CONTROL
E/R JUNCTION BOX
E/R-A
E/R-B
ECM (M/T) PCM (A/T) (LEFT REAR OF ENGINE COMPT)
FRONT WIPER (LOW) RELAY
FRONT WIPER HIGH RELAY
FRONT WIPER MOTOR (LEFT REAR ENGINE COMPT)
FRONT WIPER SWITCH
GRN WIRE
GRN/ORG WIRE
GRY WIRE
HOT IN ON
HOT IN ON OR START SMART JUNCTION BOX CLUSTER (LEFT END FUSE OF DASH)
I/P-C
I/P-F
INSTRUMENT CLUSTER
J/C
JOINT CONNECTOR
LO INT OFF HI
M/T
MICOM
MIST SWITCH
MULTI- FUNCTION SWITCH
OFF
ORG/ WIRE
PARKING SWITCH
PCM (LEFT REAR OF ENGINE COMPT)
PNK WIRE
TRANSCEIVER/
WASHER LEVEL SENSOR (IN WASHER FLUID RESERVOIR)
WASHER SWITCH
WHT WIRE
WIPER FRT 1 FUSE
WIPER FRT 2 FUSE
WIPER FUSE
WIPER SWITCH INPUT
WIPER WASHER MOTOR (ON WASHER FLUID RESERVOIR)
YEL WIRE
YEL/BLK WIRE
Go to component -> Front wiper/washer circuit -> 32 33 COMPUTER DATA LINES SYSTEM SIG 1 GND
