Kia Soul I facelift (2011-2014) tail gate latch ptc Wiring diagram
This page shows the only wiring diagram for the component.tail gate latch ptc, which is found in the car Kia Soul I facelift (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tail gate latch ptc (1 of 1)
BCM TAIL GATE (RIGHT SIDE RELAY CTRL OF DASH)
BLK WIRE
BLU WIRE
GRN WIRE
HOT AT ALL TIMES
I/P JUNCTION BOX (LEFT SIDE OF DASH)
I/P-FI
I/P-MA
MOTOR
NCA WIRE
ORG/ WIRE
PNK W/ REAR VIEW CAMERA W/O REAR VIEW CAMERA WIRE
PNK WIRE
SMART KEY CONTROL MODULE
T/GATE OPEN FUSE
TAIL GATE LATCH PTC
TAIL GATE OPEN SWITCH
TAIL GATE RELAY
TAIL GATE UNLOCK SW INPUT
TAIL- GATE HANDLE SWITCH
W/ REAR W/O REAR VIEW VIEW CAMERA CAMERA
Go to component -> Tailgate release circuit -> TAIL GATE LATCH PTC
