Kia Soul I facelift (2011-2014) room lamp control tail gate switch Wiring diagram

B-CAN LOW B-CAN TRANSCEIVER BCM (RIGHT SIDE OF DASH) BLK WIRE BLU WIRE BLU/RED WIRE BODY COMPUTER SYSTEM W/ REAR VIEW CAMERA W/O REAR VIEW CAMERA BRN WIRE CENTER ROOM LAMP COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM B-CAN HIGH DOOR DOOR OPEN IND DRIVER RIGHT DOOR REAR SWITCH DOOR SWITCH FRONT DOOR SWITCH DRIVER FRONT DOOR SWITCH PASSENGER FUSE GND DR(-) GRN WIRE GRN/ORG WIRE GRY WIRE GRY/ORG WIRE HIGH LOW HOT AT ALL TIMES HOT IN ACC OR ON I/P JUNCTION BOX (LEFT SIDE OF DASH) I/P-FH I/P-MB I/P-MD INSTRUMENT CLUSTER LEFT REAR DOOR SWITCH LEFT REAR DOOR SWITCH RIGHT REAR DOOR SWITCH LEFT VANITY LAMP ON OFF LUGGAGE LAMP MAP MCU OFF OFF OFF ON ON ORG/ WIRE ORG/BLK WIRE OVERHEAD MAP LAMP CONSOLE ASSEMBLY PASSENGER DOOR SWITCH POWER POWER CONNECTOR RED WIRE RIGHT VANITY LAMP ON OFF ROOM LAMP CONTROL TAIL GATE SWITCH ROOM LP FUSE TAIL GATE LATCH TAIL GATE OPEN IND TAIL GATE OPEN SWITCH
