Wiring diagram right h/lp fuse left h/lp fuse (1 of 2)
1 2 8 DRL B+ DRL B+ H/LP (HI) RLY CTRL
19 10 DRL (RH) DRL (LH)
2.0L
22 10 21 FRT FOG RLY CTRL TAIL LP SW IN H/LP SW PNK WIRE
23 2 4 20 1 18 TURN SIG LH POWER SIG GND AUTO LIGHT SW ON H/LP HI SW
8 9 10 23 24 B-CAN HI B-CAN LO H/LP LO SIG HAZARD SIG TURN SIG RH
AUTO LIGHT SENSOR
BCM (RIGHT SIDE OF DASH)
BLK WIRE
BLK/ORG WIRE
BLOWER RELAY
BLU WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DASH PANEL)
DEDICATE DRL FUSE
DIMMER, PASSING SWITCH
DRL RLY CTRL
E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FRT FOG RLY CTRL
GRN WIRE
GRN/ORG WIRE
GRY WIRE
H/LP FUSE
H/LP HI
H/LP HI FUSE
H/LP RELAY
H/LP RLY CTRL
HI DRL IND
HI LO DRL IND
HIGH PASS
HOT AT ALL TIMES
LEFT HEAD- LAMP
LIGHT SWITCH
LOW LOW
MULTIFUNCTION SWITCH
ORG/ WIRE
PASS FRONT FOG LAMP SWITCH HIGH OFF
PNK PNK WIRE
PNK WIRE
RED WIRE
RED/ORG WIRE
RED/WHT WIRE
RELAY
RIGHT H/LP FUSE LEFT H/LP FUSE
RIGHT HEAD- LAMP
TAIL HEAD OFF
TAIL HEAD OFF AUTO AUTO
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Headlights circuit, with drl (1 of 2) -> RIGHT H/LP FUSE LEFT H/LP FUSE
Wiring diagram right h/lp fuse left h/lp fuse (2 of 2)
2 4 20 1 18 POWER SIG GND AUTO LIGHT SW ON H/LP HI SW
22 10 21 FRT FOG RLY CTRL TAIL LP SW IN H/LP SW PNK WIRE
8 9 10 B-CAN HI B-CAN LO H/LP LO SIG
AUTO LIGHT SENSOR
BCM (RIGHT SIDE OF DASH)
BLK WIRE
BLK/ORG WIRE
BLOWER RELAY
BLU WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DASH PANEL)
DIMMER, PASSING SWITCH
E/R FUSE, RELAY BOX (LEFT SIDE OF ENGINE COMPT)
FRT FOG RLY CTRL
GRN WIRE
GRN/ORG WIRE
GRY WIRE
H/LP (HI) RLY CTRL
H/LP FUSE
H/LP HI
H/LP HI FUSE
H/LP RELAY
H/LP RLY CTRL
HI LO
HIGH PASS
HOT AT ALL TIMES
LEFT HEAD- LAMP
LIGHT SWITCH
LOW LOW
MULTIFUNCTION SWITCH
ORG/ WIRE
PASS FRONT FOG LAMP SWITCH HIGH OFF
PNK PNK WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
RELAY
RIGHT H/LP FUSE LEFT H/LP FUSE
RIGHT HEAD- LAMP
TAIL HEAD OFF
TAIL HEAD OFF AUTO AUTO
YEL WIRE
YEL/ORG WIRE
Go to component -> Headlights circuit, without drl (1 of 2) -> RIGHT H/LP FUSE LEFT H/LP FUSE
