Kia Soul I facelift (2011-2014) rear wiper int Wiring diagram
This page shows the only wiring diagram for the component.rear wiper int, which is found in the car Kia Soul I facelift (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear wiper int (1 of 1)
2.0L
AUTO PARKING SWITCH
BCM (RIGHT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CIRCUIT
DASH)
FRONT
GRY WIRE
HOT IN ON
I/P JUNCTION BOX (LEFT SIDE OF
I/P-FI
I/P-MA
INT OFF WASHER SWITCH ON ON OFF
MULTIFUNCTION SWITCH
ORG/ WIRE
REAR
REAR WIPER INT
REAR WIPER MOTOR (TAILGATE DOOR)
REAR WIPER RELAY
REAR WIPER SWITCH
REAR WIPER SWITCH REAR WASHER
SWITCH
W/ REAR VIEW CAMERA
W/O REAR VIEW CAMERA
WASHER MOTOR (RIGHT SIDE ENGINE COMPT)
WIPER RR FUSE
WIPER/ WASHER
YEL WIRE
Go to component -> Rear wiper/washer circuit -> REAR WIPER INT
