Kia Soul I facelift (2011-2014) power outside mirror switch Wiring diagram
This page shows the only wiring diagram for the component.power outside mirror switch, which is found in the car Kia Soul I facelift (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power outside mirror switch (1 of 1)
BLK WIRE
BRN WIRE
DEFOGGER
DEFOGGER SYSTEM
DOWN
DRIVER POWER OUTSIDE MIRROR
FUSE (LEFT SIDE OF DASH) I/P-FI
GRN/BLK WIRE
GRY WIRE
HOT IN ACC OR ON
I/P JUNCTION BOX
LEFT
LEFT RIGHT
LEFT SELECTOR SWITCH
LEFT/ RIGHT UP/ DOWN
NCA WIRE
ORG/ WIRE
OUTSIDE MIRROR MOTOR
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
POWER OUTSIDE MIRROR SWITCH
RED WIRE
RIGHT
RIGHT SELECTOR SWITCH
SELECTOR SWITCH
UP/ DOWN DOWN UP UP
UP/ DOWN LEFT/ RIGHT
VL HL
VR HR
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit -> POWER OUTSIDE MIRROR SWITCH
