Kia Soul I facelift (2011-2014) one touch flasher flasher unit unit Wiring diagram
This page shows the only wiring diagram for the component.one touch flasher flasher unit unit, which is found in the car Kia Soul I facelift (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram one touch flasher flasher unit unit (1 of 1)
A/C A/C CONTROL CONTROL MODULE MODULE
A/C CONTROL MODULE
A/V NAVIGATION TOUCH
A/V, NAVIGATION HEAD UNIT
A/V, NAVIGATION HEAD UNIT SHIELD
ACTIVE ECO SWITCH
ATM SHIFT LEVER INDICATOR
AUDIO
AUDIO SHIELD
AUTO A/C
AUTO MANUAL A/C A/C
AUX JACK
AUX, USB JACK
BCM
BCM ISG RHEOSTAT SWITCH
BLK WIRE
CIGARETTE LIGHTER
DASH PANEL)
DATA LINK CONNECTOR
DOOR UNLOCK RELAY DOOR LOCK RELAY
FET (FIELD EFFECT TRANSISTOR)
FOB SMART KEY HOLDER CONTROL MODULE
GLOVE BOX LAMP)
I/P-MD
IG 1 RELAY IG 2 RELAY
INSTRUMENT CLUSTER
JOINT CONNECTOR JMB
JOINT CONNECTOR JMB (RIGHT KICK PANEL)
MANUAL A/C
MOOD LAMP MODULE
MULTIFUNCTION SWITCH
NAVIGATION
NCA WIRE
ONE TOUCH FLASHER FLASHER UNIT UNIT
PDM
RELAY
RF FRONT RECEIVER POWER OUTLET
SMART KEY CONTROL MODULE
SPORT MODE SWITCH
SRS CONTROL MODULE
STANDARD AUDIO
STOP LAMP RELAY
TELLTALE LAMP
TIRE PRESSURE MONITORING MODULE
TRIP SWITCH
UVO UVO AUDIO AUDIO
W/O LED W/ LED POSITION POSITION LAMP LAMP
Go to component -> Ground distribution circuit (1 of 4) -> ONE TOUCH FLASHER FLASHER UNIT UNIT
