Kia Soul I facelift (2011-2014) m-can hi m-can lo a/v, navigation head unit Wiring diagram
This page shows the only wiring diagram for the component.m-can hi m-can lo a/v, navigation head unit, which is found in the car Kia Soul I facelift (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram m-can hi m-can lo a/v, navigation head unit (1 of 1)
A/C CONTROL MODULE
A/T
AMP (RIGHT SIDE OF TRUNK)
AUDIO
AUTO A/C
AUTO MANUAL A/C A/C
B-CAN HI B-CAN LO
B-CAN LO B-CAN HI C-CAN LO C-CAN HI
BCM (RIGHT SIDE OF DASH)
BLK WIRE
BLU WIRE
C-CAN
C-CAN C-CAN
C-CAN LO C-CAN HI EPS CONTROL MODULE (CENTER OF DASH)
C-CAN LO C-CAN HI ESC MODULE (REAR OF ENGINE COMPT)
C-CAN LO C-CAN HI TIRE PRESSURE MONITORING MODULE (RIGHT SIDE OF DASH)
GRN WIRE
HI LO
INSTRUMENT CLUSTER
J/C JMC (RIGHT SIDE OF DASH)
J/C JMF (BEHIND CENTER OF DASH)
LO HI HI LO
M-CAN HI M-CAN LO
M-CAN HI M-CAN LO A/C CONTROL MODULE (AUTO)
M-CAN HI M-CAN LO A/V, NAVIGATION HEAD UNIT
M-CAN HI M-CAN LO A/V, NAVIGATION TOUCH
M-CAN LO M-CAN HI
M/T
MANUAL A/C
ORG/ WIRE
PCM (LEFT REAR ENGINE COMPT)
PDM
RED WIRE
SMART KEY CONTROL MODULE
W/ PREMIUM
YEL WIRE
Go to component -> Computer data lines circuit (2 of 2) -> M-CAN HI M-CAN LO A/V, NAVIGATION HEAD UNIT
