Kia Soul I facelift (2011-2014) key lock key unlk Wiring diagrams
This page contains all the electrical diagrams for the component. key lock key unlk, in which he is found in the car Kia Soul I facelift (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram key lock key unlk (1 of 2)
2 TURN UNLOCK RLY CTRL
6 7 18 DR LOCK RLY CTRL DR UNLOCK RLY CTRL
BCM (RIGHT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
DRIVER DOOR LOCK ACTUATOR (DRIVER DOOR)
GRN WIRE
GRY WIRE
KEY LOCK KEY UNLK
LOCK UNLK
PASSENGER DOOR LOCK ACTUATOR (FRONT PASSENGER DOOR)
PNK WIRE
POWER WINDOW SW (UNLOCK)
RED WIRE
RED/ORG WIRE
RR DR UNLOCK SW IN
UN- LOCK LOCK
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Forced entry circuit (1 of 2) -> KEY LOCK KEY UNLK
Wiring diagram key lock key unlk (2 of 2)
2 TURN UNLOCK RLY CTRL
6 7 18 DR LOCK RLY CTRL DR UNLOCK RLY CTRL
BCM (RIGHT SIDE OF DASH)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
DRIVER DOOR LOCK ACTUATOR (DRIVER DOOR)
GRN WIRE
GRY WIRE
KEY LOCK KEY UNLK
LOCK UNLK
PASSENGER DOOR LOCK ACTUATOR (FRONT PASSENGER DOOR)
PNK WIRE
POWER WINDOW SW (UNLOCK)
RED WIRE
RED/ORG WIRE
RR DR UNLOCK SW IN
UN- LOCK LOCK
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power door locks circuit (1 of 2) -> KEY LOCK KEY UNLK
