Kia Soul I facelift (2011-2014) c-can high c-can low clutch sw vehicle spd Wiring diagram
This page shows the only wiring diagram for the component.c-can high c-can low clutch sw vehicle spd, which is found in the car Kia Soul I facelift (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram c-can high c-can low clutch sw vehicle spd (1 of 1)
ACCEL PEDAL MODULE (TOP OF ACCELERATOR PEDAL BRACKET)
ANTI-THEFT SYSTEM
APS 1 GND APS 2 GND ON/ST INPUT ST CTRL RLY C/FAN HI C/FAN LO
APS 1 POWER APS 2 POWER PNK WIRE
APS 1 SIG APS 2 SIG
APT SIG
BLK WIRE
BLU WIRE
BRAKE SW
BRN WIRE
BRN/BLK WIRE
C-CAN HIGH C-CAN LOW CLUTCH SW VEHICLE SPD
CLOSED W/ BRAKE PEDAL DEPRESSED
CLUTCH SWITCH
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
ENGINE CTRL F/PUMP CTRL
ESC MODULE
FTPS/ATP/BVS
GRN WIRE
GRN/ORG WIRE
GRY WIRE
IMMO LINE
OPEN W/ BRAKE PEDAL DEPRESSED
PDM
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
STARTING/ CHARGING SYSTEM
WHT WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Wiring diagram engine performance 2.0l, mfi control circuit, m/t (5 of 5) -> C-CAN HIGH C-CAN LOW CLUTCH SW VEHICLE SPD
