Kia Sorento IV facelift (2023-2024) w/o multi focus reflector Wiring diagram
This page shows the only wiring diagram for the component.w/o multi focus reflector, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o multi focus reflector (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
LEFT HEADLAMP
NCA WIRE
ORG/BLK WIRE
PASSENGER POWER OUTSIDE MIRROR
PNK/BLK WIRE
POSITION LAMP
RED/BLK WIRE
RED/ORG WIRE
RIGHT HEADLAMP
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP
STOP LAMP
TAIL LAMP
TURN ACTUATOR
TURN LAMP
W/ LED
W/ MULTI- FOCUS REFLECTOR
W/O LED
W/O MULTI FOCUS REFLECTOR
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Exterior lamps circuit, hybrid (2 of 4) -> W/O MULTI FOCUS REFLECTOR
