Kia Sorento IV facelift (2023-2024) wireless dcu fuse Wiring diagram
This page shows the only wiring diagram for the component.wireless dcu fuse, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wireless dcu fuse (1 of 1)
10 WAY 8 WAY
14-WAY
BRN WIRE
DATA LINK CONNECTOR
DCU
DRIVER LUMBAR SUPPORT SWITCH
DRIVER POWER SEAT SWITCH
DRIVER SAFETY POWER WINDOW MODULE
FROM MULTI FUSE-2 (DIAGRAM 1 OF 11)
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HAZARD SWITCH
IMS CONTROL MODULE
INVERTER FUSE
KEY SOLENOID
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SAFETY POWER WINDOW MODULE
MODULE 7 FUSE
ORG/ WIRE
ORG/BLK WIRE
P/SEAT (DRV) FUSE
P/SEAT PASS FUSE
P/WINDOW LH FUSE
P/WINDOW RH FUSE
PASSENGER POWER SEAT SWITCH
PASSENGER POWER WINDOW SWITCH
PASSENGER SAFETY POWER WINDOW MODULE
PDC
PDC-A
PDC-C
PDC-D
PDC-E
PNK WIRE
POWER TAILGATE FUSE
POWER TAILGATE UNIT
RAIN SENSOR
RED WIRE
RED/BLK WIRE
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SAFETY POWER WINDOW MODULE
S/HEATER FRT FUSE
SUNROOF FUSE
SUNROOF MOTOR (MASTER-GLASS)
TO AC INVERTER (DIAGRAM 8 OF 11)
W/ AUTO UP DOWN, SAFETY
W/ MEMORY
W/ POWER SEAT
W/ SEAT WARMER
W/O AUTO UP/ DOWN, SAFETY
W/O MEMORY
W/O SEAT WARMER
WHT WIRE
WIRELESS DCU FUSE
YEL WIRE
Go to component -> Power distribution circuit, except hybrid (5 of 11) -> WIRELESS DCU FUSE
