Kia Sorento IV facelift (2023-2024) vess speaker Wiring diagram
This page shows the only wiring diagram for the component.vess speaker, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vess speaker (1 of 1)
B+3 FUSE
BLK WIRE
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
GROUND
GRY/BLK WIRE
GRY/ORG WIRE
HEV
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-A
ICU-B
ICU-G
M-CAN HIGH
M-CAN LOW
MEMORY POWER
MODULE 3 FUSE
ON/START INPUT
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
VESS SPEAKER
VESS UNIT
WHT/BLK WIRE
Go to component -> Active bodyworks circuit -> VESS SPEAKER
