Kia Sorento IV facelift (2023-2024) t/sig lp rl t/sig lp rr Wiring diagram
This page shows the only wiring diagram for the component.t/sig lp rl t/sig lp rr, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram t/sig lp rl t/sig lp rr (1 of 1)
BACK-UP
BACKUP LAMPS CIRCUIT
BACKUP LP
BLK WIRE
BRAKE LAMP
BRAKE LP LH
E/R JUNCTION BLOCK
EXT TAIL LP RL
EXTERIOR LAMPS CIRCUIT
GRN/BLK WIRE
GRN/ORG WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-C
ICU-D
IPS CONTROL MODULE
IPS CTRL
LAMP
LH REAR
MEMORY POWER
NCA WIRE
RED/BLK WIRE
RH REAR
T/SIG LP RL T/SIG LP RR
TAIL LAMP
TRAILER FUSE
TRAILER MODULE (LEFT REAR OF LUGGAGE COMPT)
TURN SIG LMP
WHT WIRE
WHT/BLK WIRE
Go to component -> Trailer tow circuit, hybrid -> T/SIG LP RL T/SIG LP RR
