Kia Sorento IV facelift (2023-2024) transaxle range sw ground Wiring diagram
This page shows the only wiring diagram for the component.transaxle range sw ground, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transaxle range sw ground (1 of 1)
A/T
B+1 FUSE
BACKUP LAMP
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CTRL
DCT
E/R JUNCTION BLOCK
ELECTROCHROMIC MIRROR
GRN WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
IPS
IPS CONTROL MODULE
LEFT BACKUP LAMP
MULTI FUSE 1
ORG/ WIRE
ORG/BLK WIRE
P-CAN HIGH
P-CAN LOW
PCM (A/T) TCM (DCT)
PDC-B
PDC-C
PDC-E
PDC-F
PNK GROUND WIRE
PNK WIRE
POWER
RED/BLK WIRE
RIGHT BACKUP LAMP
SIGNAL 1
SIGNAL 2
TRANSAXLE RANGE SW GROUND
TRANSAXLE RANGE SW POWER
TRANSAXLE RANGE SW SIGNAL 1
TRANSAXLE RANGE SW SIGNAL 2
TRANSAXLE RANGE SWITCH
W/ DCM
W/O DCM
YEL WIRE
YEL/BLK WIRE
Go to component -> Backup lamps circuit, except hybrid -> TRANSAXLE RANGE SW GROUND
