Kia Sorento IV facelift (2023-2024) trailer brk curr in Wiring diagram
This page shows the only wiring diagram for the component.trailer brk curr in, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trailer brk curr in (1 of 1)
B+1 FUSE
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CURR OUT
E-BRK
E-BRK STP IN/OUT
E/R JUNCTION BLOCK
EXTERIOR LIGHTS CIRCUIT
GRN WIRE
GRN/ORG WIRE
GROUND
HMSL
HOT AT ALL TIMES
IPS CONTROL MODULE
IPS CTRL
MEMORY POWER
MEMORY PWR
MULTI FUSE 1
ORG/ WIRE
PDC
PDC-B
PDC-C
STOP LAMP
STP IN/OUT
TRAILER 1 FUSE
TRAILER 2 FUSE
TRAILER 3 FUSE
TRAILER BRK
TRAILER BRK CURR IN
TRAILER CONTROLLER
TRAILER MODULE
WHT/ORG WIRE
YEL WIRE
Go to component -> Trailer tow circuit, except hybrid -> TRAILER BRK CURR IN
