Kia Sorento IV facelift (2023-2024) thermistor out Wiring diagram
This page shows the only wiring diagram for the component.thermistor out, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram thermistor out (1 of 1)
A/C 1 FUSE
BLK WIRE
BLK/ORG WIRE
BLOWER FUSE
BLOWER RELAY
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
BRN/WHT WIRE
DEFOGGER SYSTEM
E/R JUNCTION BLOCK
ELECTRONIC REFRIGERANT REDUCED PRESSURE VALVE
EWP 1 FUSE
FRONT A/C CONTROL PANEL
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HAZARD SW IND
HAZARD SW SIG
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-A
ILL
IN-CAR TEMPERATURE SENSOR
ITS
MEMORY PWR
MODULE 9 FUSE
MTR 1 -
MTR 2 -
MTR 3
MTR 4
ON INPUT
ON/START INPUT
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
PRESSURE OUT
PWR
REAR A/C CONTROL MODULE
REAR DEFOGGER IND
RED WIRE
REFRIGERANT TEMPERATURE, PRESSURE SENSOR
THERMISTOR OUT
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> 1.6l turbo plug-in hybrid, automatic a/c circuit (2 of 7) -> THERMISTOR OUT
