Kia Sorento IV facelift (2023-2024) temp sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.temp sensor 2, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram temp sensor 2 (1 of 1)
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BMS ASSEMBLY
BMS CONTROL MODULE
BRN WIRE
C/FAN PWR
C/FAN RLY CTRL
CONTROL CONNECTOR
COOLING FANS SYSTEM
CURRENT SENSOR
FROM BMS CONTROL MODULE (DIAGRAM 4 OF 7)
FROM MAIN BATTERY MODULE 9 (DIAGRAM 7 OF 7)
HV BATT GND
HV BATT SIG
HV-P
INTERLOCK -
MAIN BATTERY MODULE TEMPERATURE SENSOR 1
MAIN BATTERY MODULE TEMPERATURE SENSOR 3
MAIN BATTERY TEMPERATURE MODULE SENSOR 2
MAIN BATTERY TEMPERATURE MODULE SENSOR 4
MAIN NEGATIVE RELAY
MAIN POSITIVE RELAY
MAIN RLY
ORG/ WIRE
PNK WIRE
PNK/ORG WIRE
POWER RELAY ASSEMBLY
PR-A-IN
PR-A-IP
PRA-BP
PRA-HS
PRE CHARGE RELAY
PRE-CHARGE RESISTOR
PRE-CHARGE RLY
RED WIRE
SIG
SPEED
TEMP SENSOR 1
TEMP SENSOR 2
TO MAIN BATTERY MODULE 1 (DIAGRAM 6 OF 7)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 1.6l turbo hybrid, hybrid control circuit (5 of 7) -> TEMP SENSOR 2
