Kia Sorento IV facelift (2023-2024) switch sensing mirror select left sw mirror select right sw mirror position sw Wiring diagram
This page shows the only wiring diagram for the component.switch sensing mirror select left sw mirror select right sw mirror position sw, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram switch sensing mirror select left sw mirror select right sw mirror position sw (1 of 1)
ANALOG SENSING LOCK
BCW IND
BDC
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER
DOOR CAMERA
DRIVER IMS SWITCH
FILTER
FOLDING
FOLDING MOTOR
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
ILL
IMS SET
IMS SW INPUT
INTERFACE
LIMIT SWITCH
MCU
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
OUTSIDE MIRROR
OUTSIDE MIRROR CONTROL (IMS)
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
PNK/BLK WIRE
RED WIRE
SWITCH SENSING MIRROR SELECT LEFT SW MIRROR SELECT RIGHT SW MIRROR POSITION SW
TURN LAMP
UNFOLDING
UP/ DOWN LEFT/ RIGHT
V OUT
YEL WIRE
Go to component -> Memory mirrors circuit, expect hybrid (2 of 2) -> SWITCH SENSING MIRROR SELECT LEFT SW MIRROR SELECT RIGHT SW MIRROR POSITION SW
