Kia Sorento IV facelift (2023-2024) steering wheel steering wheel heated module Wiring diagram
This page shows the only wiring diagram for the component.steering wheel steering wheel heated module, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering wheel steering wheel heated module (1 of 1)
ADAS UNIT (DRIVING)
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLUETOOTH UNIT (MASTER)
CARGO LAMP
CCU
CLOCKSPRING
CLUSTER UNIT
CRASH PAD SWITCH
DATA LINK CONNECTOR
ELECTROCHROMIC MIRROR
FRONT USB CHARGE CONNECTOR
FRONT VIEW CAMERA (ADAS)
FRONT WIRELESS CHARGER UNIT
GLOVE BOX LAMP)
HAZARD SWITCH
HEAD-UP DISPLAY
IGNITION KEY ILL, DOOR WARNING SWITCH
IPS CONTROL MODULE
LEFT PERSONAL LAMP
LEFT VANITY LAMP
MULTI- FUNCTION SWITCH
NCA WIRE
OVERHEAD CONSOLE
PDC-E
PDC-F
RAIN SENSOR
RIGHT PERSONAL LAMP
RIGHT VANITY LAMP
ROA (REAR OCCUPANT ALERT)
ROOM LAMP
STEERING WHEEL HAPTIC STEERING WHEEL MOTOR
STEERING WHEEL STEERING WHEEL HEATED MODULE
SUNROOF SWITCH
TRAILER CONTROLLER
UWB UNIT (ROOF)
W/ DCM
W/ DIGITAL KEY
W/ LED
W/ SUNROOF
W/O LED W/O DCM
W/O SUNROOF
Go to component -> Ground distribution circuit, except hybrid (1 of 8) -> STEERING WHEEL STEERING WHEEL HEATED MODULE
