Kia Sorento IV facelift (2023-2024) sens power Wiring diagram
This page shows the only wiring diagram for the component.sens power, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sens power (1 of 1)
B+3 FUSE
BACKUP LAMP
BLK WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CTRL
E/R JUNCTION BLOCK
ELECTROCHROMIC MIRROR
GRN WIRE
GROUND
GRY/ORG WIRE
HOT AT ALL TIMES
ICU JUNCTION BLOCK
ICU-B
ICU-D
ICU-G
ICU-H
IPS
IPS CONTROL MODULE
LEFT BACKUP LAMP
MULTI FUSE 1
NCA WIRE
ORG/ WIRE
P-CAN
P-CAN HIGH
P-CAN LOW
POSITION SENSOR (TOP OF TRANSAXLE)
POWER
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT BACKUP LAMP
SBW CONTROL UNIT
SENS GROUND
SENS POWER
SIGNAL 1
SIGNAL 2
TRAILER MODULE
YEL WIRE
YEL/BLK WIRE
Go to component -> Backup lamps circuit, hybrid -> SENS POWER
