Kia Sorento IV facelift (2023-2024) right rear console usb charger connector Wiring diagram
This page shows the only wiring diagram for the component.right rear console usb charger connector, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear console usb charger connector (1 of 1)
1.6L TURBO HYBRID
1.6L TURBO PLUG-IN HYBRID
A/V, NAVIGATION HEAD UNIT
ADAS UNIT
AMP
AUDIO
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/ORG WIRE
DRIVER SEAT USB CHARGE CONNECTOR
FROM ICU JUNCTION BLOCK (DIAGRAM 9 OF 12)
FROM PCB JUNCTION BLOCK (DIAGRAM 2 OF 12)
GRN WIRE
GRY WIRE
GRY/BLK WIRE
IBU
ICU JUNCTION BLOCK
ICU-A
ICU-C
ICU-D
ILL
LEFT FRONT USB CHARGE CONNECTOR
LEFT LUGGAGE USB CHARGE CONNECTOR
LEFT REAR CONSOLE USB CHARGE CONNECTOR
LEFT REAR SEAT ENTERTAINMENT
MODULE 1 FUSE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER SEAT USB CHARGE CONNECTOR
PNK WIRE
PNK/BLK WIRE
PNK/ORG WIRE
RED WIRE
RED/BLK WIRE
RIGHT FRONT USB CHARGE CONNECTOR
RIGHT LUGGAGE USB CHARGE CONNECTOR
RIGHT REAR CONSOLE USB CHARGER CONNECTOR
RIGHT REAR SEAT ENTERTAINMENT
SURROUND VIEW MONITOR UNIT
USB CHARGER 1 FUSE
USB CHARGER 2 FUSE
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Power distribution circuit, hybrid (3 of 12) -> RIGHT REAR CONSOLE USB CHARGER CONNECTOR
