Kia Sorento IV facelift (2023-2024) right front tire pressure sensor Wiring diagrams
This page contains all the electrical diagrams for the component. right front tire pressure sensor, in which he is found in the car Kia Sorento IV facelift (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right front tire pressure sensor (1 of 2)
'B' OUTPUT
AMP FUSE
B+ INPUT
BDC
BDC 1 FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CLUSTER UNIT
COMPUTER DATA LINES SYSTEM
E-CAN TRANSCEIVER
GRY/ORG WIRE
HOT AT ALL TIMES
HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED
HS HIGH
HS LOW
LEFT FRONT TIRE PRESSURE SENSOR
LEFT REAR TIRE PRESSURE SENSOR
MCU
MEMORY POWER
MULTI MEDIA 1 FUSE
MULTI MEDIA 2 FUSE
ON/START INPUT
PDC
PDC-C
PDC-E
PNK WIRE
POWER
POWER DISTRIBUTION SYSTEM
POWER GND
RED WIRE
RELAY ENERGIZED
RIGHT FRONT TIRE PRESSURE SENSOR
RIGHT REAR TIRE PRESSURE SENSOR
SIG GND 1
SMPS
TPMS (YELLOW) IND
W/ 12.3 INCH LCD
W/ AMP
W/O AMP
WHT WIRE
Go to component -> Tire pressure monitoring circuit, except hybrid -> RIGHT FRONT TIRE PRESSURE SENSOR
Wiring diagram right front tire pressure sensor (2 of 2)
B-CAN HIGH
B-CAN LOW
BLK WIRE
BLU WIRE
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
GRY WIRE
HOT W/
IBU
IBU 1 FUSE
ICU JUNCTION BLOCK
ICU-F
ICU-G
INSTRUMENT CLUSTER
LEFT FRONT TIRE PRESSURE SENSOR
LEFT REAR TIRE PRESSURE SENSOR
M-CAN
MCU
ON/START INPUT
POWER DISTRIBUTION SYSTEM
PWR GND
RED WIRE
RIGHT FRONT TIRE PRESSURE SENSOR
RIGHT REAR TIRE PRESSURE SENSOR
SIG GND 1
TPMS IND (W/ 4.2 INCH LCD)
TRANSCEIVER/
W/ 12.3 INCH LCD
WHT/BLK WIRE
YEL WIRE
Go to component -> Tire pressure monitoring circuit, hybrid -> RIGHT FRONT TIRE PRESSURE SENSOR
