Kia Sorento IV facelift (2023-2024) passenger safety power window switch Wiring diagram
This page shows the only wiring diagram for the component.passenger safety power window switch, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger safety power window switch (1 of 1)
10-WAY
8 WAY
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
GRN WIRE
GRY WIRE
LUGGAGE POWER OUTLET
NCA WIRE
ORG/ WIRE
PASSENGER AIR VENTILATION SEAT BLOWER MOTOR
PASSENGER POWER OUTSIDE MIRROR
PASSENGER POWER SEAT SWITCH
PASSENGER POWER WINDOW SWITCH
PASSENGER SAFETY POWER WINDOW SWITCH
PASSENGER SEAT USB CHARGE CONNECTOR
REAR A/C CONTROL MODULE
REAR FET (FIELD EFFECT TRANSISTOR)
REAR SEAT FOLDING SWITCH
RIGHT LUGGAGE USB CHARGE CONNECTOR
RIGHT REAR COMBINATION LAMP
RIGHT REAR DOOR LOCK ACTUATOR
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR SAFETY POWER WINDOW MODULE
RIGHT REAR SEAT ENTERTAINMENT
W/ AUTO UP/DOWN, SAFETY
W/ CHILD LOCK
W/ MEMORY
W/ WARMER
W/O AUTO UP/DOWN, SAFETY
W/O CHILD LOCK
W/O MEMORY
W/O WARMER
WHT WIRE
WHT/ORG WIRE
Go to component -> Ground distribution circuit, except hybrid (7 of 8) -> PASSENGER SAFETY POWER WINDOW SWITCH
