Kia Sorento IV facelift (2023-2024) oil pump control unit Wiring diagrams
This page contains all the electrical diagrams for the component. oil pump control unit, in which he is found in the car Kia Sorento IV facelift (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram oil pump control unit (1 of 2)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
COMMAND MTR SPD
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
ELECTRONIC OIL PUMP (LOWER LEFT REAR OF ENGINE)
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HIGH VOLTAGE JUNCTION BLOCK
HOT AT ALL TIMES
HOT W/
INTER LOCK
MEM PWR
NCA WIRE
OIL PUMP CONTROL UNIT
ON/START INPUT
OPCU FUSE
OPU STATUS
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PCB JUNCTION BLOCK
PCB-B
POS SENS GND
POS SENS PWR
POS SIG U
POS SIG V
POS SIG W
PUMP PWR-U
PUMP PWR-V
PUMP PWR-W
PWM COMMAND
PWR INPUT (+)
RED WIRE
SENS GND
SENS PWR
SENSOR 8 FUSE
SHIELD
STATUS OPU
TCM
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l turbo hybrid, electric oil pump circuit -> OIL PUMP CONTROL UNIT
Wiring diagram oil pump control unit (2 of 2)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
COMMAND MTR SPD
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
ELECTRONIC OIL PUMP (LOWER LEFT REAR OF ENGINE)
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HIGH VOLTAGE JUNCTION BLOCK
HOT AT ALL TIMES
HOT W/
INTER LOCK
MEM PWR
NCA WIRE
OIL PUMP CONTROL UNIT
ON/START INPUT
OPCU FUSE
OPU STATUS
ORG/ WIRE
P-CAN HIGH
P-CAN LOW
PCB JUNCTION BLOCK
PCB-B
POS SENS GND
POS SENS PWR
POS SIG U
POS SIG V
POS SIG W
PUMP PWR-U
PUMP PWR-V
PUMP PWR-W
PWM COMMAND
PWR INPUT (+)
RED WIRE
SENS GND
SENS PWR
SENSOR 8 FUSE
SHIELD
STATUS OPU
TCM
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l turbo plug-in hybrid, electric oil pump circuit -> OIL PUMP CONTROL UNIT
