Kia Sorento IV facelift (2023-2024) nca Wiring diagrams

This page contains all the electrical diagrams for the component. nca, in which he is found in the car Kia Sorento IV facelift (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

nca wiring diagram (161 of 182)

BLK WIRE BLK/ORG WIRE BLU WIRE BLU/ORG WIRE COMMAND MTR SPD COMPUTER DATA LINES SYSTEM E/R JUNCTION BLOCK ELECTRONIC OIL PUMP (LOWER LEFT REAR OF ENGINE) GRN WIRE GRY WIRE GRY/ORG WIRE HIGH VOLTAGE JUNCTION BLOCK HOT AT ALL TIMES HOT W/ INTER LOCK MEM PWR NCA WIRE OIL PUMP CONTROL UNIT ON/START INPUT OPCU FUSE OPU STATUS ORG/ WIRE P-CAN HIGH P-CAN LOW PCB JUNCTION BLOCK PCB-B POS SENS GND POS SENS PWR POS SIG U POS SIG V POS SIG W PUMP PWR-U PUMP PWR-V PUMP PWR-W PWM COMMAND PWR INPUT (+) RED WIRE SENS GND SENS PWR SENSOR 8 FUSE SHIELD STATUS OPU TCM WHT WIRE YEL WIRE

Go to component -> Wiring diagram engine performance 1.6l turbo plug-in hybrid, electric oil pump circuit -> NCA WIRE

nca wiring diagram (162 of 182)

BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/ORG WIRE CLUSTER SYSTEM COMPUTER CURR ADJUST CURR PMP DATA LINES DATA LINES SYSTEM DIFFERENTIAL PRESSURE SENSOR ELCM OUT (MTR) ELCM OUT VLV ELCM P SENS SIG ELECTRONIC WASTEGATE SENSOR ENG CTRL RLY CTRL FPS GND FPS INPUT FPS PWR FUEL PMP RLY CTRL FUEL SNDR GRN WIRE GRN/ORG WIRE GRY WIRE GRY/BLK WIRE GRY/ORG WIRE H-CAN HI H-CAN LO IMMO DATA LINE INSTRUMENT L-CAN HI L-CAN LO LIN 1 MEM PWR NCA WIRE OCV EX CTRL OCV IN CTRL ORG/ WIRE P-CAN HI PCSV GND PNK WIRE PNK/BLK WIRE PRESSURE CONTROL VALVE PURGE CONTROL SOLENOID VALVE PWR RED WIRE RED/BLK WIRE RED/ORG WIRE SENS (DOWN) HTR SENS HTR SIG SYSTEM SYSTEM CRUISE CONTROL VEH SPD INPUT VIRTUAL GND VOLT NERNST WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE

Go to component -> Wiring diagram engine performance 1.6l turbo plug-in hybrid, engine controls circuit (4 of 8) -> NCA WIRE

nca wiring diagram (163 of 182)

BLK WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/ORG WIRE ECU 1 FUSE FRONT ACTIVE PURGE PUMP SENSOR FUEL TANK PRESSURE SENSOR GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRY WIRE GRY/BLK WIRE GRY/ORG WIRE HOT AT ALL TIMES MAIN RELAY MAP SENSOR (ON INTAKE MANIFOLD) NCA WIRE OIL LEVEL SENSOR ORG/ WIRE OXYGEN SENSOR (UP) (IN EXHAUST MANIFOLD) PCB JUNCTION BLOCK PCB-B PCB-C PNK WIRE PNK/BLK WIRE PWR RAIL PRESSURE SENSOR RED WIRE RED/ORG WIRE SENSOR 1 FUSE SENSOR 2 FUSE SENSOR 3 FUSE SENSOR 4 FUSE SENSOR 5 FUSE SENSOR 6 FUSE SENSOR 7 FUSE SIG WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/ORG WIRE

Go to component -> Wiring diagram engine performance 1.6l turbo plug-in hybrid, engine controls circuit (5 of 8) -> NCA WIRE

nca wiring diagram (164 of 182)

BATTERY MODULE 2 BATTERY SYSTEM ASSEMBLY (UNDER LEFT SIDE OF VEHICLE) BLK/ORG WIRE BRN WIRE BUS BAR CMU 2 GRN WIRE GRY/ORG WIRE NCA WIRE OPD HI OPD HO OPD LI OPD LO ORG/ WIRE PNK WIRE RXNH RXNL RXPH RXPL TXNH TXNL TXPH TXPL WHT WIRE YEL WIRE

Go to component -> Wiring diagram engine performance 1.6l turbo plug-in hybrid, hybrid control circuit (10 of 12) -> NCA WIRE

nca wiring diagram (165 of 182)

BATTERY MODULE 3 BATTERY MODULE TEMPERATURE SENSOR 3 BATTERY SYSTEM ASSEMBLY (UNDER LEFT SIDE OF VEHICLE) BLK/ORG WIRE BLU WIRE BRN WIRE BSA TEMP SENS 3 GND BSA TEMP SENS 3 SIG BUS BAR CMU 3 FUSE GRN WIRE GRY/ORG WIRE N/A NCA WIRE OPD HI OPD HO OPD LI OPD LO ORG/ WIRE PNK WIRE RED WIRE RXNH RXNL RXPH RXPL SIG TXNH TXNL TXPH TXPL WHT WIRE YEL WIRE

Go to component -> Wiring diagram engine performance 1.6l turbo plug-in hybrid, hybrid control circuit (11 of 12) -> NCA WIRE

nca wiring diagram (166 of 182)

BATTERY MODULE 4 BATTERY MODULE TEMPERATURE SENSOR 4 BATTERY SYSTEM ASSEMBLY (UNDER LEFT SIDE OF VEHICLE) BLK/ORG WIRE BLU WIRE BRN WIRE BSA TEMP SENS 4 GND BSA TEMP SENS 4 SIG BUS BAR CMU 4 GRN WIRE GRY/ORG WIRE NCA WIRE OPD HI OPD HO OPD LI OPD LO ORG/ WIRE PNK WIRE RED WIRE RXNH RXNL RXPH RXPL SIG TXNH TXNL TXPH TXPL WHT WIRE YEL WIRE

Go to component -> Wiring diagram engine performance 1.6l turbo plug-in hybrid, hybrid control circuit (12 of 12) -> NCA WIRE

nca wiring diagram (167 of 182)

AMS FUSE ASSEMBLY (DIAGRAM 8 OF 12) BATTERY JUNCTION BLOCK BATTERY MANAGEMENT FUSE BLK WIRE BLU WIRE BLU/ORG WIRE COMPUTER DATA LINES SYSTEM E-CAN TRANSCEIVER E/R JUNCTION BLOCK EXTERNAL CHARGING CABLE IND GRN WIRE GRN/ORG WIRE GRY WIRE HEV RLY B/UP HPCU 1 FUSE IBU (RIGHT SIDE OF HVAC UNIT) ILL PWR INSTRUMENT CLUSTER MCU (W/ 4.2 INCH LCD) NCA WIRE ORG/BLK WIRE P-CAN HIGH P-CAN LOW PNK WIRE RED WIRE RED/BLK WIRE SIG GND 1 SSB SSB ILL SSB SW 1 SSB SW 2 START FEEDBACK START RLY START/STOP BUTTON SWITCH SUB BATTERY SW 1 SW 2 TO BATTERY SYSTEM W/ 12.3 INCH LCD WHT WIRE YEL/ORG WIRE

Go to component -> Wiring diagram engine performance 1.6l turbo plug-in hybrid, hybrid control circuit (3 of 12) -> NCA WIRE

nca wiring diagram (168 of 182)

BATTERY SYSTEM ASSEMBLY (UNDER LEFT SIDE OF VEHICLE) BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BUS BAR CURRENT SENSOR GRN WIRE GRY WIRE GRY/ORG WIRE INTERLOCK - MAIN RELAY N/A NCA WIRE OBC (+) RELAY OBC FUSE ORG/ WIRE ORG/BLK WIRE PNK/ORG WIRE POWER RELAY ASSEMBLY PRE CHARGE RELAY PRE- CHARGE REGISTER RED WIRE RED/ORG WIRE RED/WHT WIRE TEMPERATURE SENSOR TERMINAL BLOCK TO HIGH VOLTAGE JUNCTION BLOCK (DIAGRAM 1 OF 12) TO OBC UNIT (DIAGRAM 4 OF 12) YEL WIRE YEL/BLK WIRE YEL/ORG WIRE YEL/WHT WIRE

Go to component -> Wiring diagram engine performance 1.6l turbo plug-in hybrid, hybrid control circuit (7 of 12) -> NCA WIRE

nca wiring diagram (169 of 182)

BATTERY MODULE TEMPERATURE SENSOR 2 BLK WIRE BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BLU/ORG WIRE BLU/WHT WIRE BMU+ BRN WIRE BSA TEMP SENS 2 GND COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM EMERGENCY INTERLOCK GND FROM E/R JUNCTION BLOCK (DIAGRAM 3 OF 12) FROM E/R JUNCTION BLOCK (DIAGRAM 5 OF 12) G-CAN HIGH G-CAN LOW GRN WIRE GRY WIRE GRY/ORG WIRE H-CAN HIGH H-CAN LOW INLET TEMP SENS GND INLET TEMP SENS SIG INLET TEMPERATURE SENSOR LAKE SENSOR 1 LAKE SENSOR 2 MEMORY PWR NCA WIRE OBC CONNECTOR INTERLOCK HIGH OBC CONNECTOR INTERLOCK LOW ORG/ WIRE ORG/BLK WIRE PNK WIRE PRA (+) TEMP SENS GND PRA (-) TEMP SENS PRA (-) TEMP SENS BSA TEMP SENS 2 SIG PRA TEMP SENS SIG RED WIRE RED/ORG WIRE RED/WHT WIRE SIG SUPPLEMENTAL RESTRAINTS SYSTEM WATER PUMP (LIN) CRASH SIG YEL WIRE YEL/BLK WIRE YEL/WHT WIRE

Go to component -> Wiring diagram engine performance 1.6l turbo plug-in hybrid, hybrid control circuit (8 of 12) -> NCA WIRE

nca wiring diagram (170 of 182)

BATTERY MODULE 1 BATTERY MODULE TEMPERATURE SENSOR 1 BATTERY SYSTEM ASSEMBLY (UNDER LEFT SIDE OF VEHICLE) BLK/ORG WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BSA TEMP SENS 1 GND BSA TEMP SENS 1 SIG BUS BAR CMU 1 GRN WIRE GRY WIRE GRY/ORG WIRE NCA WIRE OPD HI OPD HO OPD LI OPD LO ORG/ WIRE PNK WIRE RED WIRE RED/WHT WIRE RXNH RXNL RXPH RXPL SIG TXNH TXNL TXPH TXPL WHT WIRE YEL WIRE

Go to component -> Wiring diagram engine performance 1.6l turbo plug-in hybrid, hybrid control circuit (9 of 12) -> NCA WIRE
