Kia Sorento IV facelift (2023-2024) mirror control vcc block Wiring diagram
This page shows the only wiring diagram for the component.mirror control vcc block, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror control vcc block (1 of 1)
BCW IND
BDC 2 FUSE
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
BRN/BLK WIRE
COMM
COMPUTER DATA LINES SYSTEM
DEFOGGER
DEFOGGER SYSTEM
DEFOGGER, EXTERIOR LIGHTS SYSTEMS
DOOR CAMERA
DRIVER DOOR AREA UNIT (CENTER OF DRIVER DOOR)
DRIVER POWER OUTSIDE MIRROR
EXTERIOR LIGHTS SYSTEMS
EXTERIOR LIGHTS, DEFOGGER SYSTEMS
FILTER
FOLDING
FOLDING MOTOR
GRN/ORG WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT RIGHT
LIMIT SWITCH
MCU
MIRROR CONTROL VCC BLOCK
MODULE 2 FUSE
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
OUTSIDE MIRROR
OUTSIDE MIRROR PASSENGER POWER OUTSIDE MIRROR
PDC
PDC-C
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RELAY ENERGIZED
TRANSCEIVER/
TURN LAMP
UNFOLDING
UP DOWN
V OUT
YEL/BLK WIRE
Go to component -> Power mirrors circuit, except hybrid -> MIRROR CONTROL VCC BLOCK
