Kia Sorento IV facelift (2023-2024) (lower left rear of engine compt, Wiring diagrams
This page contains all the electrical diagrams for the component. (lower left rear of engine compt,, in which he is found in the car Kia Sorento IV facelift (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram (lower left rear of engine compt, (1 of 2)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BLUETOOTH UNIT (MASTER)
BRN WIRE
C-CAN FD HIGH
C-CAN FD LOW
DRIVER SMART KEY OUTSIDE HANDLE
ESC MODULE
GRN WIRE
GRY WIRE
LEFT FRONT UWB UNIT
ORG/ WIRE
ORG/BLK WIRE
P-CAN FD HIGH
P-CAN FD LOW
PNK WIRE
RIGHT END OF DASH)
RIGHT FRONT UWB UNIT
UWB L-CAN HIGH
UWB L-CAN LOW
UWB UNIT (ROOF)
W/ EPB
WHT WIRE
WHT/RED WIRE
Go to component -> Computer data lines circuit, except hybrid (6 of 7) -> (LOWER LEFT REAR OF ENGINE COMPT,
Wiring diagram (lower left rear of engine compt, (2 of 2)
B-CAN HI
B-CAN LO
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
C-CAN FD HI
C-CAN FD LO
CENTER CONSOLE
CVVD ACTUATOR
ELECTRONIC SHIFT DIAL
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRY/ORG WIRE
H-CAN FD HI
H-CAN FD LO
IEB UNIT
ORG/ WIRE
ORG/BLK WIRE
P-CAN FD HI
P-CAN FD LO
POWER TAILGATE UNIT
PT L-CAN 1 HI
PT L-CAN 1 LO
PT LOCAL-CAN
REAR CAMERA
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT END OF DASH)
TCM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Computer data lines circuit, hybrid (3 of 6) -> (LOWER LEFT REAR OF ENGINE COMPT,
