Kia Sorento IV facelift (2023-2024) left door lock actuator Wiring diagram
This page shows the only wiring diagram for the component.left door lock actuator, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left door lock actuator (1 of 1)
10-WAY
8 WAY
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
CHILD LOCK 1 RELAY
CHILD LOCK 2 RELAY
DOOR LOCK RELAY
DOOR UNLOCK RELAY
DRIVER AIR VENTILATION SEAT BLOWER MOTOR
DRIVER DOOR AREA UNIT
DRIVER LUMBAR SUPPORT SWITCH
DRIVER POWER OUTSIDE MIRROR
DRIVER POWER SEAT SWITCH
DRIVER SAFETY POWER WINDOW MODULE
DRIVER SEAT USB CHARGE CONNECTOR
F-29
FUEL PUMP CONTROL MODULE
GRY WIRE
IMS CONTROL MODULE
LEFT BACKUP LAMP
LEFT DOOR LOCK ACTUATOR
LEFT LUGGAGE USB CHARGE CONNECTOR
LEFT REAR COMBINATION LAMP
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SAFETY POWER WINDOW MODULE
LEFT REAR SEAT ENTERTAINMENT
NCA WIRE
PDC-D
PNK/BLK WIRE
POWER TAILGATE UNIT
REAR CONSOLE POWER OUTLET
REAR DEFOGGER
RIGHT BACKUP LAMP
SUNROOF MOTOR (GLASS)
SUNROOF MOTOR (ROLLER)
TRAILER MODULE
TWO TURN UNLOCK RELAY
W/ AUTO UP/DOWN, SAFETY
W/ MEMORY
W/ MEMORY W/O MEMORY
W/O AUTO UP/DOWN, SAFETY
W/O CHILD LOCK W/ CHILD LOCK
W/O MANUAL SEAT
W/O MEMORY
Go to component -> Ground distribution circuit, except hybrid (5 of 8) -> LEFT DOOR LOCK ACTUATOR
