Kia Sorento IV facelift (2023-2024) front pdw sensor gnd Wiring diagram
This page shows the only wiring diagram for the component.front pdw sensor gnd, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front pdw sensor gnd (1 of 1)
BDC (UNDER RIGHT END OF DASH)
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ECU GND
FLOOR CONSOLE SWITCH
FRONT PDW SENSOR GND
FRONT PDW SENSOR PWR
GRN WIRE
GRY WIRE
HOT W/ LONG TERM LOAD LATCH RELAY ENERGIZED
LEFT FRONT PDW SENSOR (IN)
LEFT FRONT PDW SENSOR (OUT)
LEFT PARKING DISTANCE WARNING FORWARD SENSOR (IN)
LEFT PARKING DISTANCE WARNING FORWARD SENSOR (OUT)
LEFT REAR PDW SENSOR (IN)
LEFT REAR PDW SENSOR (OUT)
MEMORY FUSE
ORG/ WIRE
ORG/BLK WIRE
PDC
PDC-E
PDW PWR
PDW SWITCH
PDW SWITCH IND
PDW SWITCH SIG
PNK WIRE
POWER GND
PWR
REAR PDW SENSOR GND
REAR PDW SENSOR PWR
RED WIRE
RED/BLK WIRE
RIGHT FRONT PDW SENSOR (IN)
RIGHT FRONT PDW SENSOR (OUT)
RIGHT PARKING DISTANCE WARNING FORWARD SENSOR (IN)
RIGHT PARKING DISTANCE WARNING FORWARD SENSOR (OUT)
RIGHT REAR PDW SENSOR (IN)
RIGHT REAR PDW SENSOR (OUT)
SIG
WHT WIRE
YEL WIRE
Go to component -> Parking assistant circuit, except hybrid w/o adas (1 of 2) -> FRONT PDW SENSOR GND
