Kia Sorento IV facelift (2023-2024) drv door door sw sw Wiring diagram
This page shows the only wiring diagram for the component.drv door door sw sw, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv door door sw sw (1 of 1)
AJAR
B+1 FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CARGO LAMP
DOOR
DOOR OPEN SWITCH
DOOR SW IND
DRV DOOR DOOR SW SW
E/R JUNCTION BLOCK
HOT AT ALL TIMES
IPS
IPS CARGO LP CTRL
IPS CONTROL MODULE
LAMP LOAD
LEFT MAP IND
LEFT REAR DOOR LOCK ACTUATOR
LH REAR DOOR SW
MCU
MODULE 8 FUSE
MULTI FUSE 1
OFF
ORG/ WIRE
ORG/BLK WIRE
OVERHEAD CONSOLE (W/ LED)
PASS
PDC
PDC-B
PDC-C
PDC-D
PDC-E
PDC-F
RED WIRE
RH REAR DOOR SW
RIGHT MAP IND
RIGHT REAR DOOR LOCK ACTUATOR
ROOM LAMP SWITCH
ROOM LP
ROOM LP OUT
ROOM SW IND
W/ CHILD LOCK
W/ LED
W/ SUNROOF
W/O CHILD LOCK
W/O LED
W/O SUNROOF
WHT WIRE
WHT/ BLU WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Courtesy lamps circuit, except hybrid (1 of 2) -> DRV DOOR DOOR SW SW
