Kia Sorento IV facelift (2023-2024) driver power switch Wiring diagram
This page shows the only wiring diagram for the component.driver power switch, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver power switch (1 of 1)
A/C FUSE
AIR BAG 2 FUSE
AMP FUSE
ATM SHIFT LEVER
AUTOMATIC A/C
BDC
BLK WIRE
BLU WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
DRIVER POWER SWITCH
DRIVER SMART KEY OUTSIDE HANDLE
E/R JUNCTION BLOCK
FROM MULTI FUSE-2 (DIAGRAM 1 OF 11)
FROM PCB BLOCK (DIAGRAM 2 OF 11)
FRONT A/C CONTROL MODULE
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
ICU-D
IMS CONTROL MODULE
LOCAL-CAN
MANUAL A/C
MEMORY POWER
MODULE 5 FUSE
MODULE 6 FUSE
MODULE 8 FUSE
MULTI- FUNCTION SWITCH
NCA WIRE
ON INPUT
ORG/ WIRE
ORG/BLK WIRE
PASSENGER POWER OUTSIDE MIRROR
PASSENGER SMART KEY OUTSIDE HANDLE
PDC
PDC-A
PDC-B
PDC-C
PDC-D
PDC-E
PNK WIRE
PNK/BLK WIRE
POWER TAILGATE UNIT
PTC HEATER
REAR A/C BLOWER MOTOR
REAR A/C CONTROL MODULE
REAR A/C FUSE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
SRS CONTROL MODULE
TO AC INVERTER (DIAGRAM 8 OF 11)
TO REAR CONSOLE AC INVERTER OUTLET (DIAGRAM 8 OF 11)
W/ MEMORY
WASHER FUSE
WHT WIRE
YEL/ORG WIRE
Go to component -> Power distribution circuit, except hybrid (4 of 11) -> DRIVER POWER SWITCH
