Kia Sorento IV facelift (2023-2024) dcu reset Wiring diagram
This page shows the only wiring diagram for the component.dcu reset, which is found in the car Kia Sorento IV facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dcu reset (1 of 1)
ACC/ON INPUT
ANT-C
ANT-RGSC
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CCU (WAKE-UP)
CRASH PAD ANTENNA
DCU (CENTER OF DASH)
DCU RESET
DIAGNOSIS CIRCUIT
E-CAN FD HIGH
E-CAN FD LOW
FRONT CONSOLE SWITCH
FRONT VIEW CAMERA (ADAS)
FRONT WIRELESS CHARGER UNIT
GRN WIRE
GRY WIRE
HS HIGH
HS LOW
IMS CONTROL MODULE
LT GRN WIRE
MATCHING CIRCUIT
MEMORY POWER
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
ROOF ANTENNA
UWB L-CAN HIGH
UWB L-CAN LOW
W/ VENTILATION SEAT
W/O VENTILATION SEAT
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Computer data lines circuit, except hybrid (7 of 7) -> DCU RESET
