Kia Sorento IV (2020-2024) w/o rear adas Wiring diagrams
This page contains all the electrical diagrams for the component. w/o rear adas, in which he is found in the car Kia Sorento IV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/o rear adas (1 of 2)
Go to component -> Computer data lines circuit, except hybrid (2 of 5) -> W/O REAR ADAS
Wiring diagram w/o rear adas (2 of 2)
ADAS UNIT
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BRN WIRE
C-CAN HI
C-CAN LO
E-CAN 1 HI
E-CAN 1 LO
E-CAN HI
E-CAN LO
FRONT A/C CONTROL MODULE
FRONT CAMERA (ADAS)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY/BLK WIRE
GRY/ORG WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER OCCUPANT DETECTION SENSOR
RED WIRE
RED/ORG WIRE
RED/WHT WIRE
RIGHT REAR CORNER RADAR UNIT
W/ FRONT ADAS
W/ REAR ADAS
W/O FRONT ADAS
W/O REAR ADAS
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Computer data lines circuit, hybrid (2 of 5) -> W/O REAR ADAS
