Kia Sorento IV (2020-2024) wireless antenna Wiring diagrams
This page contains all the electrical diagrams for the component. wireless antenna, in which he is found in the car Kia Sorento IV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram wireless antenna (1 of 2)
ACC/ON INPUT
AGC
AM/FM
AM/FM ANTENNA
AM/FM GNSS OUT/B+ OUT/VIN
AMP
AUDIO
BACKUP SIG
BLK WIRE
BLU/BLK WIRE
BPF
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
GNSS
GNSS ANTENNA
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HPF
ILL
ILL (+) M-CAN HIGH
ILL (-) M-CAN LOW
LDO
LNA
LPF
LTE
LTE OUT
MATCHING CIRCUIT
MEMORY POWER
MIC 1 (-) VM DETECT 2 (SVM GND)
MIC 1+
MIC 2+
NCA WIRE
ON/START INPUT
PNK WIRE
RED WIRE
ROOF ANTENNA
USB D (-) USB D VCC
USB D VCC
USB D-
USB GND
USB JACK
WHT WIRE
WIRELESS ANTENNA
YEL WIRE
YEL/BLK WIRE
Go to component -> Radio circuit, hybrid w/o navigation & amplifier (4 of 4) -> WIRELESS ANTENNA
Wiring diagram wireless antenna (2 of 2)
ACC/ON INPUT
AGC
AM/FM
AM/FM ANTENNA
AM/FM GNSS OUT/B+ OUT/VIN
AMP
AUDIO
BACKUP SIG
BLK WIRE
BLU/BLK WIRE
BPF
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
GNSS
GNSS ANTENNA
GRN WIRE
GRY WIRE
GRY/ORG WIRE
HPF
ILL
ILL (+) M-CAN HIGH
ILL (-) M-CAN LOW
LDO
LNA
LPF
LTE
LTE OUT
MATCHING CIRCUIT
MEMORY POWER
MIC 1 (-) VM DETECT 2 (SVM GND)
MIC 1+
MIC 2+
NCA WIRE
ON/START INPUT
PNK WIRE
RED WIRE
ROOF ANTENNA
USB D (-) USB D VCC
USB D VCC
USB D-
USB GND
USB JACK
WHT WIRE
WIRELESS ANTENNA
YEL WIRE
YEL/BLK WIRE
Go to component -> Radio circuit, hybrid w/o navigation w/ amplifier (5 of 5) -> WIRELESS ANTENNA
