Kia Sorento IV (2020-2024) sens scl Wiring diagrams
This page contains all the electrical diagrams for the component. sens scl, in which he is found in the car Kia Sorento IV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sens scl (1 of 2)
AMBIENT TEMP SEN
AMBIENT TEMPERATURE SENSOR
AUTO DEFOG ACTUATOR CLOSE
AUTO DEFOG ACTUATOR F/B
AUTO DEFOG ACTUATOR OPEN
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
COOLING FAN FUSE
E/R JUNCTION BLOCK
EVAPORATOR SENS (+)
FRONT A/C CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INTAKE ACTUATOR F/B
INTAKE ACTUATOR FRE
INTAKE ACTUATOR REC
LH MODE ACTUATOR DEF
LH MODE ACTUATOR F/B
LH MODE ACTUATOR VENT
LH PHOTO SENS (-)
LH TEMP ACTUATOR COOL
LH TEMP ACTUATOR F/B
LH TEMP ACTUATOR WARM
MULTI FUSE 1
MULTI FUSE 2
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
PTC HEATER
PTC HEATER 1 FUSE
PTC HEATER RELAY
RED WIRE
RH PHOTO SENS (-)
RH TEMP ACTUATOR COOL
RH TEMP ACTUATOR F/B
RH TEMP ACTUATOR WARM
SENS SCL
SENS SDA
SENS TEMP
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit, except hybrid (4 of 5) -> SENS SCL
Wiring diagram sens scl (2 of 2)
AMBIENT TEMP SEN
AMBIENT TEMPERATURE SENSOR
AUTO DEFOG ACTUATOR CLOSE
AUTO DEFOG ACTUATOR F/B
AUTO DEFOG ACTUATOR OPEN
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
E/R JUNCTION BLOCK
ECU 3 FUSE
ELECTRIC WATER PUMP (ENGINE)
EVAPORATOR SENS (+)
EWP 2 FUSE
FRONT A/C CONTROL MODULE
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
INPUT
INTAKE ACTUATOR F/B
INTAKE ACTUATOR FRE
INTAKE ACTUATOR REC
LEFT DUCT SENS (FLOOR)
LEFT DUCT SENS (VENT)
LH MODE ACTUATOR DEF
LH MODE ACTUATOR F/B
LH MODE ACTUATOR VENT
LH PHOTO SENS (-)
LH TEMP ACTUATOR COOL
LH TEMP ACTUATOR F/B
LH TEMP ACTUATOR WARM
MEMORY PWR
MULTI FUSE 1
ON/START
ORG/ WIRE
PCB JUNCTION BLOCK
PCB-C
PNK WIRE
PNK/BLK WIRE
PTC HEATER 1 FUSE
PTC HEATER 1 RELAY
PTC HEATER 2 FUSE
PTC HEATER 2 RELAY
RED WIRE
RED/WHT WIRE
RELAY ENERGIZED
RH MODE ACTUATOR DEF
RH MODE ACTUATOR F/B
RH MODE ACTUATOR VENT
RH PHOTO SENS (-)
RH TEMP ACTUATOR COOL
RH TEMP ACTUATOR F/B
RH TEMP ACTUATOR WARM
RIGHT DUCT SENS (FLOOR)
RIGHT DUCT SENS (VENT)
RIGHT DUCT SENSOR (VENT)
RIGHT END OF DASH)
SENS SCL
SENS SDA
SENS TEMP
WHT WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Automatic a/c circuit, hybrid (4 of 6) -> SENS SCL
