Kia Sorento IV (2020-2024) right rear console usb charger connector Wiring diagrams
This page contains all the electrical diagrams for the component. right rear console usb charger connector, in which he is found in the car Kia Sorento IV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right rear console usb charger connector (1 of 2)
A/C ON SW
A/C SWITCH
ADAS UNIT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
DRIVER SEAT USB CHARGE CONNECTOR
FROM INVERTER FUSE (DIAGRAM 3 OF 10)
FROM PCB BLOCK (DIAGRAM 2 OF 10)
GRN WIRE
GROUND
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
IBU
ICU JUNCTION BLOCK
ICU-A
ICU-D
ICU-G
ILL
LED
LED IND
LEFT FRONT USB CHARGER CONNECTOR
LEFT LUGGAGE USB CHARGER CONNECTOR
LEFT REAR CONSOLE USB CHARGER CONNECTOR
LT GRN WIRE
MEMORY PWR
MODULE 1 FUSE
ON INPUT
PASSENGER SEAT USB CHARGE CONNECTOR
PNK WIRE
REAR CONSOLE AC INVERTER OUTLET
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RIGHT FRONT USB CHARGER CONNECTOR
RIGHT LUGGAGE USB CHARGER CONNECTOR
RIGHT REAR CONSOLE USB CHARGER CONNECTOR
SURROUND VIEW MONITOR UNIT
TO LOW DC-DC CONVERTER (DIAGRAM 9 OF 10)
USB CHARGER 1 FUSE
USB CHARGER 2 FUSE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit, except hybrid (8 of 10) -> RIGHT REAR CONSOLE USB CHARGER CONNECTOR
Wiring diagram right rear console usb charger connector (2 of 2)
A/V, NAVIGATION HEAD UNIT
ADAS UNIT
AMP
AUDIO
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
DRIVER SEAT USB CHARGE CONNECTOR
FROM ICU JUNCTION BLOCK (DIAGRAM 8 OF 10)
FROM PCB JUNCTION BLOCK (DIAGRAM 2 OF 10)
GRN WIRE
GRY WIRE
GRY/BLK WIRE
IBU
ICU JUNCTION BLOCK
ICU-A
ICU-C
ICU-D
ICU-G
ILL
LEFT FRONT USB CHARGER CONNECTOR
LEFT LUGGAGE USB CHARGER CONNECTOR
LEFT REAR CONSOLE USB CHARGER CONNECTOR
LEFT REAR SEAT ENTERTAINMENT
MODULE 1 FUSE
ORG/BLK WIRE
PASSENGER SEAT USB CHARGE CONNECTOR
PNK WIRE
PNK/BLK WIRE
PNK/ORG WIRE
RED WIRE
RED/BLK WIRE
RIGHT FRONT USB CHARGER CONNECTOR
RIGHT LUGGAGE USB CHARGER CONNECTOR
RIGHT REAR CONSOLE USB CHARGER CONNECTOR
RIGHT REAR SEAT ENTERTAINMENT
SURROUND VIEW MONITOR UNIT
USB CHARGER 1 FUSE
USB CHARGER 2 FUSE
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLK WIRE
YEL/ORG WIRE
Go to component -> Power distribution circuit, hybrid (3 of 10) -> RIGHT REAR CONSOLE USB CHARGER CONNECTOR
