Kia Sorento IV (2020-2024) right parking distance warning reverse sensor Wiring diagram
This page shows the only wiring diagram for the component.right parking distance warning reverse sensor, which is found in the car Kia Sorento IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right parking distance warning reverse sensor (1 of 1)
ACTIVE PURGE PUMP
BLK WIRE
BLK/ORG WIRE
BRN/ORG WIRE
BRN/YEL WIRE
CVVD ACTUATOR
DRIVER DOOR LOCK ACTUATOR
DRIVER IMS SWITCH
DRIVER POWER OUTSIDE MIRROR
DRIVER SMART KEY OUTSIDE HANDLE
ELECTRONIC A/C COMPRESSOR
ELECTRONIC OIL PUMP SHIELD
ELECTRONIC SHIFT DIAL
ELECTRONIC WATER PUMP (ENGINE)
ELECTRONIC WATER PUMP (HEV)
FRONT CONSOLE SWITCH
GRY WIRE
GRY/ORG WIRE
HPCU
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IMS CONTROL MODULE
LEFT CENTER PARKING DISTANCE WARNING REVERSE SENSOR
LEFT FRONT SEAT VENTILATION SWITCH
LEFT FRONT SEAT WARMER SWITCH
LEFT LUGGAGE USB CHARGE CONNECTOR
LEFT PARKING DISTANCE WARNING REVERSE SENSOR
LEFT REAR CORNER RADAR UNIT
LEFT SIDE PARKING DISTANCE WARNING REVERSE SENSOR
MASS AIR FLOW SENSOR (SHIELD)
NCA WIRE
PASSENGER DOOR LOCK ACTUATOR
PASSENGER POWER OUTSIDE MIRROR
PASSENGER SMART KEY OUTSIDE HANDLE
POWER TAILGATE UNIT
RIGHT CENTER PARKING DISTANCE WARNING REVERSE SENSOR
RIGHT FRONT SEAT VENTILATION SWITCH
RIGHT FRONT SEAT WARMER SWITCH
RIGHT PARKING DISTANCE WARNING REVERSE SENSOR
RIGHT SIDE PARKING DISTANCE WARNING REVERSE SENSOR
W/ MEMORY
W/ VENTILATION W/O VENTILATION
Go to component -> Ground distribution circuit, hybrid (6 of 7) -> RIGHT PARKING DISTANCE WARNING REVERSE SENSOR
