Kia Sorento IV (2020-2024) right front a/c temperature actuator Wiring diagrams
This page contains all the electrical diagrams for the component. right front a/c temperature actuator, in which he is found in the car Kia Sorento IV (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
right front a/c temperature actuator wiring diagram (1 of 2)
AUTO DEFOGGER ACTUATOR
AUTO DEFOGGER SENSOR
AUTO LIGHT, PHOTO SENSOR
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
EVAPORATOR SENSOR
GRN WIRE
GRY WIRE
LEFT FRONT A/C TEMPERATURE ACTUATOR
ORG/ WIRE
PHOTO SENSOR
PNK WIRE
PNK/BLK WIRE
PWR
RED WIRE
RIGHT FRONT A/C TEMPERATURE ACTUATOR
SCL
SDA
TEMP
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit, except hybrid (3 of 5) -> RIGHT FRONT A/C TEMPERATURE ACTUATOR
right front a/c temperature actuator wiring diagram (2 of 2)
AUTO DEFOGGER ACTUATOR
AUTO DEFOGGER SENSOR
AUTO LIGHT, PHOTO SENSOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN WIRE
BRN/ORG WIRE
DUCT SENSOR (DEF)
EVAPORATOR SENSOR
GRN WIRE
GRY WIRE
LEFT DUCT SENSOR (FLOOR)
LEFT FRONT A/C TEMPERATURE ACTUATOR
ORG/ WIRE
PHOTO SENSOR
PNK WIRE
PNK/BLK WIRE
RED WIRE
RED/WHT WIRE
RIGHT DUCT SENSOR (FLOOR)
RIGHT FRONT A/C TEMPERATURE ACTUATOR
WHT WIRE
WHT/ORG WIRE
YEL WIRE
Go to component -> Automatic a/c circuit, hybrid (3 of 6) -> RIGHT FRONT A/C TEMPERATURE ACTUATOR
