Kia Sorento IV (2020-2024) middle speed sensor Wiring diagram
This page shows the only wiring diagram for the component.middle speed sensor, which is found in the car Kia Sorento IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram middle speed sensor (1 of 1)
ATM SOLENOID VALVE (TOP OF TRANSAXLE)
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
BRN/ORG WIRE
FUEL TANK PRESSURE SENSOR
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRY WIRE
INPUT SPEED SENSOR
MIDDLE SPEED SENSOR
OIL TEMPERATURE
ORG/ WIRE
ORG/BLK WIRE
OUTPUT SPEED SENSOR
PNK WIRE
RED WIRE
RED/BLK WIRE
SENSOR
SS A
VFS (OD, LR)
VFS LINE
VFS T/CON
VFS UD
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 2.5l, engine controls circuit (3 of 8) -> MIDDLE SPEED SENSOR
