Kia Sorento IV (2020-2024) main battery module 9 Wiring diagram
This page shows the only wiring diagram for the component.main battery module 9, which is found in the car Kia Sorento IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram main battery module 9 (1 of 1)
BLU WIRE
BMS ASSEMBLY
BMS CONTROL MODULE
BRN WIRE
BUS BAR
FROM MAIN BATTERY MODULE 5 (DIAGRAM 6 OF 7)
FROM POWER RELAY ASSEMBLY (DIAGRAM 5 OF 7)
GRN WIRE
GRY WIRE
MAIN BATTERY MODULE 6
MAIN BATTERY MODULE 7
MAIN BATTERY MODULE 8
MAIN BATTERY MODULE 9
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
TO MAIN BATTERY MODULE 5 (DIAGRAM 6 OF 7)
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.6l turbo hybrid, hybrid control circuit (7 of 7) -> MAIN BATTERY MODULE 9
