Kia Sorento IV (2020-2024) lin transceiver ic Wiring diagram
This page shows the only wiring diagram for the component.lin transceiver ic, which is found in the car Kia Sorento IV (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lin transceiver ic (1 of 1)
B-CAN TRANSCEIVER IC
BCW IND
BLK WIRE
BLU WIRE
BRN/ORG (OR BLU/ORG) WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER
DOOR CAMERA
DRIVER IMS SWITCH
EXCEPT HYBRID
FOLDING
FOLDING MOTOR
GRN/BLK WIRE
GRN/ORG WIRE
GRY (OR BLK) WIRE
GRY WIRE
ILL
IMS SW
LEFT RIGHT
LIMIT SWITCH
LIN TRANSCEIVER IC
MCU
NAVIGATION SYSTEM
NCA WIRE
OUTSIDE MIRROR
OUTSIDE MIRROR CONTROL (IMS)
PASSENGER POWER OUTSIDE MIRROR
PNK WIRE
PNK/BLK WIRE
RED WIRE
RXD
SET-
TURN LAMP
TXD
UNFOLDING
UP DOWN
V OUT
VCC
VOLTAGE REGULATOR
WHT (OR GRN/ORG) WIRE
WHT WIRE
Go to component -> Memory mirrors circuit (2 of 2) -> LIN TRANSCEIVER IC
