Kia Sorento IV (2020-2024) light switch signal Wiring diagrams

B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BRAKE LP LH BRAKE LP RH BRK LIGHT SW BRN WIRE COMPUTER DATA LINES SYSTEM DEID DRL LH DEID DRL RH EXT TAIL LP FL EXT TAIL LP FR EXT TAIL RP RL EXT TAIL RR RL GRN/BLK WIRE GRN/ORG WIRE GRY WIRE GRY/ORG WIRE HEAD LAMP HI SWITCH IN HIGH MOUNTED STOP LAMP HMSL HOT W/ IBU (RIGHT SIDE OF HVAC UNIT) IBU 1 FUSE ICU JUNCTION BLOCK ICU-A ICU-C ICU-D ICU-G IPS IPS 2 CTRL IPS 4 CTRL IPS CONTROL MODULE LEFT LICENSE LAMP LEFT REAR COMBINATION LAMP LH TELL- TALE T/SIG LIGHT SWITCH SIGNAL NCA WIRE ON/START INPUT ORG/BLK WIRE PNK/BLK WIRE RED WIRE RED/BLK WIRE RED/ORG WIRE RH TELL- TALE T/SIG STOP LAMP T/SIG LP FL T/SIG LP FR TAIL, SIDE MARKER LAMP TURN LAMP W/ LED W/O LED WHT WIRE WHT/BLK WIRE WHT/ORG WIRE WIPER, LIGHT GROUND YEL WIRE YEL/BLK WIRE

B-CAN HIGH B-CAN LOW BLK WIRE BLU WIRE BRAKE LP LH BRAKE LP RH BRN WIRE COMPUTER DATA LINES SYSTEM DEID DRL LH DEID DRL RH EXT TAIL LP FL EXT TAIL LP FR EXT TAIL RP RL EXT TAIL RR RL GRN/BLK WIRE GRN/ORG WIRE GRY WIRE HEAD LAMP HI SWITCH IN HIGH MOUNTED STOP LAMP HMSL HOT W/ IBU (RIGHT SIDE OF HVAC UNIT) IBU 1 FUSE ICU JUNCTION BLOCK ICU-A ICU-C ICU-D ICU-G IPS IPS 2 CTRL IPS 4 CTRL IPS CONTROL MODULE LEFT LICENSE LAMP LEFT REAR COMBINATION LAMP LH TELL- TALE T/SIG LIGHT SWITCH SIGNAL NCA WIRE ON/START INPUT ORG/BLK WIRE PNK/BLK WIRE PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/ORG WIRE RH TELL- TALE T/SIG STOP LAMP STOP LAMP SW T/SIG LP FL T/SIG LP FR TAIL LAMP TURN LAMP W/ LED W/O LED WHT WIRE WHT/BLK WIRE WHT/ORG WIRE WIPER, LIGHT GROUND YEL WIRE YEL/BLK WIRE
